Getting Started
[Eth In] 2,162,862 bytes
[Eth Tx] 1,098,403 bytes
[RF Rx] 471,841 bytes
[RF Tx] 2,233,369 bytes
Success.
#>
To view only a particular section of the sysinfo screen, type sysinfo followed by the desired section number.
Example:
#> sysinfo 2
********************************* 2 *********************************
[Opmode] on [Default Opmode] on
[Active Channel] 2 h [Freq] 5280 MHz
[Speed] 36 Mbps [Tx Power] 7 dBm [Power Range] -4..7 dBm
[Peer ID] DE1B784B [Status] connected
[Peer IP Config] 10.254.1.3 255.255.255.248 10.254.1.1
Success.
#>
Each of the parameters within the sysinfo screen is defined below
Section 0
[Model]
[Unit Type]
[Hardware Version]
[Firmware Version]
[System Up Time]
Section 1
[MAC]
[S/N]
[IP]
[Subnet Mask]
[Gateway]
Section 2
[Opmode]
[Default Opmode]
[Active Channel]
[Freq]
[Speed]
[Tx Power]
[Power Range]
[Peer ID]
[Status]
[RSSI]
Trango Broadband Wireless — Atlas5010
0 Kbps
4 Kbps
0 Kbps
0 Kbps
[RSSI] -75 dBm
Radio Model # (P5010M)
User defined Unit Type (MU or RU)
Hardware version set by factory (5010)
Current firmware version loaded in radio
Time since last reboot or power cycle
MAC address of radio
Serial Number of Radio
User defined IP Address of radio
User entered IP Subnet Mask
User entered IP address of the default router or gateway on the local
Ethernet segment
Operation mode of the radio: ON = transmitting, OFF= not transmitting
Opmode which the radio defaults to after reboot.
Active RF Channel and Antenna polarization
Frequency of active channel
Modulation Speed (6,12,18,24,36, 54 Mbps)
Transmit Power
Allowable power range for chosen Frequency (dBm)
MAC Address of remote radio
Connection status of remote radio (connected or disconnected)
Measured signal strength from remote radio (dBm)
