Trango Systems TrangoLink-45 Specification Sheet

P o I n T - T o - P o I n T H I g H - C a P a C I T Y B a C K H a U L n E T w o R K S
The TrangoLINK-45® is a 5 GHz multi-band wireless
backhaul radio that delivers up to 45 Mbps of sustained
usable data throughput using OFDM technology. The
multi-band feature provides a choice of 5.2, 5.3, 5.4 or 5.8
GHz in the convenience of one radio, enabling valuable
operational fl exibility in high RF noise environments.
With unmatched interference mitigation and carrier-class
performance, TrangoLINK-45™ off ers an exceptional value
for ISP backhaul, enterprise and municipal connectivity, IP
video surveillance, leased-line replacement and "last mile"
dedicated connectivity solutions (Internet, T1).
Industry Best Interference mitigation
»
Built-in Auto RF RX Threshold for superior interference
mitigation—maintains superb link integrity in high noise fl oor
»
Dynamic Frequency Selection (DFS) in 5.3/5.4 GHz
»
Automatic Repeat reQuest (ARQ), Forward Error Correction (FEC)
»
Automatic RF Transmit Power Control (ATPC)
» Site survey tools
management Features
»
Remote & local management via Telnet, SNMP and HTTP
»
Asymmetrical bandwidth control, and remote temperature and
input voltage measurements
»
Built-in LED alignment tool, universal mounting bracket to
minimize deployment costs
Compact/Rugged designed for outdoor deployment
»
Fully weatherized outdoor units
»
Encased in a heavy-duty aluminum housing
»
Rugged conduit adapter, while off ering a small footprint
»
Powered using Power-over-Ethernet (PoE) ensuring ease of
installation and quick deployment
© 2008 Trango Systems, Inc. All rights reserved. The content herein is subject to change without further notice. DS-9019-E
P o I n T - T o - P o I n T
TrangoLInK-45™
45 Mbps OFDM Wireless Ethernet Bridge
Multi-band: 5.2, 5.3, 5.4 or 5.8 GHz*
Highlights
•
Up to 45 Mbps usable data throughput
•
Multi-band versatility: 5.2, 5.3, 5.4, 5.8 GHz *
•
Quality of Service (QoS) and VLAN support
•
Auto RF RX Threshold for superior interference mitigation
•
Up to 45-mile range
•
Orthogonal Frequency Division Multiplexing (OFDM)
Performance & Flexibility
»
License-exempt ISM band, lower U-NII band, upper U-NII band *
»
OFDM radio with a contention-free point-to-point protocol
»
User-selectable data rates of 6, 12, 18, 24, 36, 48 and 54 Mbps
» Packet aggregation allows superior FTP performance over long
transmission ranges
»
Adaptive Rate Modulation
antenna Versatility
»
INT models feature built-in dual-polarity panel antenna
»
EXT model features two connectors for external antenna
»
All models feature horizontal or vertical antenna polarity
that is software-selectable
Channel Flexibility & Frequency agility
»
24 possible non-overlapping channels across the
U-NII and ISM bands *
»
Up to 24 channels combined with dual-polarized antennas
allows for exceptional frequency agility *
Security and authentication
»
MAC level address authentication
»
128-bit proprietary encryption, over-the-air data scrambling
»
Two-level password control via SSL for secure operation
