- Page 1 M5580M – FSU Atlas Fox Wireless Multi Mode Ethernet Bridge Subscriber Unit USER MANUAL February 13, 2006...
- Page 2 Table of Contents Trango Revision 2 Firmware V.2p0r8 Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 2...
-
Page 3: Table Of Contents
Chapter 6 Cabling and Weather Considerations...9 Weatherizing... 9 Chapter 7 SNMP ...9 Chapter 8 Firmware Upgrade Procedure ...9 Appendix B Command Set Summary ...9 Appendix A Specifications...9 Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 Trango page iii... -
Page 4: Preface
This manual covers the basic configuration and installation of the M5580M-FSU Wireless Point to Point Subscriber Unit. The M5580M-FSU consists of a radio with an internal 8 dBi. The M5580M-FSU may be used in conjunction with an optional FCC certified external reflector dish for extended transmission range. When using the reflector dish, professional installation is required. -
Page 5: Chapter 1 Overview
Overview Chapter 1 Overview Each M5580M-FSU acts as an endpoint in a point to multipoint wireless Ethernet transmission system, which provides network connectivity at, speeds up to 45 Mbps depending on the transmission distance, noise floor, and the antenna configuration. The M5580M-FSU uses either CCK or OFDM technology coupled with Automatic Repeat request (ARQ) for improved resistance to interference and noise. - Page 6 Range vs. Throughput The following table shows approximate maximum ranges (at recommended fade margins) achievable with the M5580M-FSU when associated with an M5830S-AP in CCK mode. Ranges for OFDM modes will be published when available. Table – 1 Range & Throughput (CCK mode)
- Page 7 One boot, and mounting hardware. A dual-polarized integrated antenna is located behind the radome of the M5580M-FSU. (Dish Mounting Hardware not included with the unit) Figure 1 Figure 2 (NOT INCLUDED) Figure 3 Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page...
- Page 8 The serial number and MAC address label can be found on the back of each radio. The serial number and MAC address is also provided on the system information screen. (See figure 4 & 5 below) Figure 4 Figure 5 Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page...
-
Page 9: Location Of Rj-45/Led Port
The reset button, resets all configuration settings (including IP address and password) back to factory default. Hold the reset button down for 5 seconds (until amber lights flash) while unit is powered on. Figure 6 Reset Button Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page... -
Page 10: Chapter 2 Getting Started
Note: If voltage falls below 16 volts, the power LED will go off but the Radio LED will stay on. The radio can operate down to 10.5 volts. Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page... -
Page 11: Configuration Tools
Getting Started Configuration Tools M5580M-FSU radios can be configured using either the Command Line Interface (CLI), or the Web Browser (HTTP) interface. Although both methods are comprehensive and powerful, the CLI method provides slightly more functionality. This text covers configuration through the CLI. For HTTP configuration please see Chapter 4 on page 18. -
Page 12: System Information (Sysinfo) Page
[RF Rx] 0 bytes [RF Tx] 0 bytes Success. #> Note: Four open Telnet sessions indicated in bold within the sysinfo displayed above For more information, see table #3 below. Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page... -
Page 13: Chapter 3 Configuration
Note: if you telnet into a radio within 30 seconds after reboot, the radio will remain in opmode OFF even if the default opmode is ON. Essentials to Establish a Wireless Link Configuration of the M5580M-FSU system is simple and at a minimum requires the following settings: 1. Set BASEID 2. Designate the SU ID. - Page 14 SU ID Together with Base ID, it is the unique identifier of this SU used in association. It is used Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 Related CLI Command set baseid <baseid> Example: #>Set baseid 10 set suid <suid>...
- Page 15 ICMP and ARP, to reduce the amount of unnecessary overhead introduced to the wireless link. Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 #>Set suid 3 Informational Parameter opmode su [< y>] / off This sets the radio in Opmode “SU.” Or OFF set defaultopmode <su | off>...
-
Page 16: Establishing A Wireless Link
1 h Disconnected [Broadcast Packet] on [Auto Scan AP] on [TCP/IP for AP] off [TCP/IP for Local Eth] off Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 sw 1 [<on | off>] (default is on) sw 2 [<on | off>] (default is on) sw 5 [<on|off>] (default is on) -
Page 17: Changing Ip Address
–65 dBm. Yellow LED 4 : Begins blinking when RSSI is greater or equal to –60 dBm. On continuously at –55 dBm. This is the rightmost LED. Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page... -
Page 18: Power Settings
AP to control the output power. The following sample demonstrates how to manually set the power. (Power range from 7 – 21) In this example, the user sets the power to 19dBm: #> power set 19 Tx Power = 19 dBm Success. Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page... -
Page 19: Chapter 4 Using The Http Interface
3. Leave the User name field blank and enter read write or read only Password. Press or Click OK. Default password is trango. After logging on, the system information screen will be displayed. Figure 8 Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page... -
Page 20: Site Survey
System Information displays most of the key parameters. To view description of System Information entries within the radio, click the Help link. 4. Click on Configuration Figure 9 Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 16... - Page 21 (The SU will use these entries to look for an AP to link up to) Figure 11 Click on “Save and Activate Settings” 10. Click on Activate Opmode. Figure 12 Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 17...
- Page 22 Ethernet traffic will begin to pass across the wireless link. The “Current Status” section can help you verify connection status. The signal strength (RSSI) received from the AP is also provided under this section. Figure 13 Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 18...
-
Page 23: Chapter 5 Deployment & Installation
Deployment & Installation Chapter 5 Deployment & Installation Once you are familiar with the basic operations of the M5580M-FSU, you are ready for deployment in the field. The deployment process consists of the following steps: • Site Selection • Site survey at AP and SU sites •... -
Page 24: Channel Planning
SU to a location with better line-of-sight conditions to the AP. Once you are satisfied with the RSSI reading, tighten down the SU in the optimum position. Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 -99 / -99 -99 / -99... - Page 25 The linktest command provides over-the-air throughput and packet error rate (PER) statistics for the wireless link. This command also provides RSSI at both the AP and SU. For more information and how to execute this command see the M5830 user manual. Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 Connected Connected...
-
Page 26: Mounting Hardware
Prior to deployment, insert a properly terminated Cat-5 Cable through Boot and the Foam strain relief. Connect the Cable into the M5580M-FSU’s port opening. Last, clip the front end of the boot into the unit and then clip the back end of the boot into to the unit, as shown in the photographs below. - Page 27 Deployment & Installation Figure 18: M5580M-FSU Series SU Wall Mount Figure 19: Mounting M5580M-FSU with Mounting Cradle for AD5800-25 Reflector Dish Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 23...
- Page 28 Deployment & Installation Figure 20: M5580M – FSU / AD5800 -25 Reflector Dish on Pole Figure 21: M5580M-FSU / AD5800-25 Reflector Dish on Wall Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 24...
-
Page 29: Chapter 6 Cabling And Weather Considerations
Important! The Power-over-Ethernet injector is not a weatherized device and must be located either indoors or in a weather-protected cabinet. Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 25... -
Page 30: Chapter 7 Snmp
All current SUs support SNMP via the AP. All poll most be done through the AP. See the Access 5830 User Guide for further information on SNMP. Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 26... -
Page 31: Chapter 8 Firmware Upgrade Procedure
7. To verified if the upgrade was successful, run the ver command and validate the new version. Example: #>ver [Hardware Version] 5580 [MVC Version] 3893mvc_4p5_050913.arm [Firmware Version] FSU 2p0r3D05120701 Success. Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 page 27... -
Page 32: Appendix B Command Set Summary
<time, sec> <h/v> sw [<sw #> <on/off>] Sysinfo syslog [<0/1> | clear] tftpd [on|off] Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 Displays current firmware version, MVC and hardware Description Search for near by APs. version... -
Page 33: Appendix A Specifications
Radio Dimensions Radio Weight User Interfaces Trango Broadband Wireless — M5580M-FSU (Atlas Fox) User Manual Revision 2 FCC Part 15.247, 15.407: ETSI/EN301 489-1 (7.2) (pending) –83 dBm (1600 byte packet) to –87 dBm (64 byte packet) 29dBm (8dBi Internal Antenna...
