Trango Systems Trango TrangoLink-10A Specifications

TrangoLINK-10A
™
5.8 / 5.3 GHz
Dual-Band Outdoor Wireless Ethernet Bridge
FOR EXPORT ONLY. NOT FOR U.S.A.
The TrangoLINK-10A™ point-to-point wireless Ethernet bridge offers long range and dual band
fl exibility in an easy to install, ruggedized package. Delivering up to 10 Mbps, the TrangoLINK-10A can
be deployed as a backhaul system or as a wireless alternative to leased line and multiple T1 circuits.

Product Highlights

FLEXIBILITY
The TrangoLINK-10A provides channels of operation in both the license-exempt 5.8 GHz ISM and the
5.3 GHz U-NII bands. Dual polarized antennas, combined with 11 non-overlapping channels provide
22 channel/polarity combinations for maximum frequency agility. Antenna polarity and channel selections
are remotely switchable, and selectable receiver threshold provides additional interference mitigation.
LONG RANGE
The TrangoLINK-10A offers a range of 16 km using internal antennas and up to 64 km using optional external
antennas on the TrangoLINK-10A-EXT.
SPEED
The TrangoLINK-10A effi ciently delivers 10 Mbps of real throughput for high-bandwidth backhaul applications.
MANAGEABILITY
The TrangoLINK-10A provides users with powerful remote management tools via telnet and web-browser
interfaces as well as SNMP. TrangoLINK-10A's SmartSEEK™ redundancy feature provides continuous search
and reassociation functionality.
SECURITY
The TrangoLINK-10A utilizes direct sequence spread spectrum technology, providing excellent range and
immunity to interference. MAC authentication, coupled with transmission scrambling provides a high degree
of over-the-air security.
DURABILITY, EASE OF INSTALLATION
The TrangoLINK-10A is designed for harsh outdoor environments and operates from -40° to +140° F.
Additionally, the system's Power-over-Ethernet capability ensures easy installation and quick deployment.
AFFORDABILITY
The TrangoLINK-10A offers carrier-class features and performance at an attractive price.
