Page 1: User Manual
ATLAS5010 Point-to-Point Wireless OFDM Ethernet Bridge USER MANUAL February 18, 2005 Revision xx for Firmware 0. 9pa2... -
Page 2: Table Of Contents
Weatherizing......................19 Chapter 5 SNMP ..............................20 Chapter 6 Firmware Upgrade Procedure ......................21 ....................Appendix A Using the HTTP Interface ....................................22 ......................... Appendix B Specifications ....................................23 Trango Broadband Wireless — TrangoLINK User Manual Rev. D for Firmware Ver. 1.1 page ii... - Page 3 Table of Figures Trango Trango Broadband Wireless — Atlas-45 page iii...
-
Page 4: Preface
Preface Preface This manual covers the basic configuration and installation of the ATLAS5010 Wireless Point to Point Broadband System, and applies to the following radio part numbers: P5010M-INT Unit with internal patch antenna The ATLAS5010-INT consists of two P5010M-INT radios which have internal 23 dBi antennas with electronically selectable polarization. -
Page 5: Chapter 1 Overview
The ATLAS5010 is a point-to-point (PtP) wireless Ethernet transmission system provides network connectivity at speeds up to 45 Mbps depending on the transmission distance, noise floor, and the antenna configuration. The Atlas5010 uses is designed for use in long range backhaul and wide area data networking applications. The... -
Page 6: Range Vs. Throughput
U-NII (5250 MHz to 5350 MHz) Range & Throughput Antenna 6 miles 10 miles 15 miles Integrated 23 dBi 20 Mbps 11Mbps 6Mbps 15” Flat Panel (10 db fade margin) (12db fade margin) (9db fade margin) Line-of-sight range Trango Broadband Wireless — Atlas-45 page... -
Page 7: System Contents
Overview System Contents Each ATLAS5010 kit consists of two radios, two power-over-Ethernet (PoE) injectors, two AC adapters, port covers, and mounting hardware. A dual-polarized integrated antenna is located behind the radome of the P5010M- INT. Location of Serial Number & MAC Address The serial number and MAC address label can be found on the back of each radio. -
Page 8: Location Of Rj-45/Led Port
The reset button resets all configuration settings (including IP address and password) back to factory default. Hold the reset button down for 5 seconds (until amber lights flash) while unit is powered on. Reset Button Trango Broadband Wireless — Atlas-45 page... -
Page 9: Chapter 2 Getting Started
The radio requires approximately 45 seconds to boot. Configuration Tools ATLAS5010 radios can be configured using either the Command Line Interface (CLI), or the Web Browser (HTTP) interface. Although both methods are comprehensive and powerful, the CLI method provides slightly more functionality. -
Page 10: Troubleshooting Ethernet Connections
You will be greeted with current hardware and firmware information and prompted for a password. Type in the password and press enter. The factory default read/write password is trango. Welcome to Trango Broadband Wireless, Atlas PtP-P5010M 0p9a2D05020401 Password: Login as read/write. - Page 11 ********************************* 5 ********************************* [Auto Rate Shift] off [RSSI LED] on [Remarks] Remarks ********************************* 6 ********************************* [Eth In] 31,117 bytes [Eth Out] 54,391 bytes [RF In] 39,574 bytes [RF Out] 54,391 bytes Success. #> Trango Broadband Wireless — ATLAS5010 page 7...
- Page 12 [Speed] 24 Mbps [Tx Power] 0 dBm [Power Range] -4..19 dBm [Tx MIR] 50000 Kbps [ARQ] on [Encrypt] off [Key] 0011 2233 4455 6677 8899 AABB CCDD EEFF [Peer ID] DE1B7850 [Status] disconnected [RSSI] -49 dBm Success. #> Trango Broadband Wireless — ATLAS5010 page 8...
-
Page 13: Chapter 3 Configuration
2. Set the Peer ID with the MAC address of the RU. Only use the last 8 digits of the MAC address. de1B7850 #> peerid Success. #> 3. Set channel and polarization. (in this example set the channel to 23 and polarization to H). #> freq 23 h Trango Broadband Wireless — ATLAS5010 page 9... -
Page 14: Remote Unit Configuration
[Speed] 24 Mbps [Tx Power] 0 dBm [Power Range] -4..19 dBm [Tx MIR] 50000 Kbps [ARQ] on [Encrypt] off [Key] 0011 2233 4455 6677 8899 AABB CCDD EEFF [Status] connected [Peer ID] DE1B7850 [RSSI] -49 dBm Success. #> Trango Broadband Wireless — ATLAS5010 page 10... -
Page 15: Changing Ip Address
ASSOCiation LED (green): The ASSOC led blinks at the following rates: - Once every second when unit is powered on but opmode is OFF. Trango Broadband Wireless — ATLAS5010 page 11... -
Page 16: Rf Link Loopback Test (Linktest Command)
The lowest power setting for all bands in –4 dBm. Speed Setting Receiver Max Power Max Power (over-the-air rate) Sensitivity High (ISM) Band Low (U-NII) (Mbps) (dB) (dBm) (dBm) Trango Broadband Wireless — ATLAS5010 page 12... -
Page 17: Command Reference Listing
Exit telnet session freq [<ch#> <antenna>] Set or display channel and antenna selection freq writechannel <ch#> <freq>… Modify channel table, up to 6 channels at a time freq writechannel default Restore factory default channel table Trango Broadband Wireless — ATLAS5010 page 13... - Page 18 1: MAC address and IP configuration part 2: RF link status part 3: channel table part 4: region code and power limitations part 5: switch settings and remarks part 6: statistics syslog Display system log Trango Broadband Wireless — ATLAS5010 page 14...
- Page 19 Deployment & Installation tftpd [on|off] Enable or disable tftpd (used for firmware upgrades) utype [mu|ru] Set or display unit type Trango Broadband Wireless — ATLAS5010 page 15...
-
Page 20: Chapter 4 Deployment & Installation
Based on the results of the site survey at each end of the link, choose a channel which offers the lowest noise floor. In order to reliably operate in the higher speed modes, clean spectrum is essential. Trango Broadband Wireless — ATLAS5010 page 16... -
Page 21: Rssi Command And Antenna Alignment
-68 dB Connected 10> MU -67 dB -67 dB Connected Success. Users can also view the RSSI LEDs on the bottom of the radio. See the configuration section of this manual for more information. Trango Broadband Wireless — ATLAS5010 page 17... -
Page 22: Mounting Hardware
Mounting Hardware Radios are supplied with mounting hardware for pole installations. See diagram below for proper use of the mounting hardware. 8.50 MAX 10.00° UPTILT 25.00° DOWNTILT Mounting Hardware Assembly for Integrated Antenna P5010-INT Trango Broadband Wireless — ATLAS5010 page 18... -
Page 23: Cabling And Weather Considerations
Important! The Power-over-Ethernet injector is not a weatherized device and must be located either indoors or in a weather-protected cabinet. Trango Broadband Wireless — ATLAS5010 page 19... -
Page 24: Chapter 5 Snmp
SNMP Chapter 5 SNMP Trango Broadband Wireless — ATLAS5010 page 20... -
Page 25: Chapter 6 Firmware Upgrade Procedure
SNMP Chapter 6 Firmware Upgrade Procedure Trango Broadband Wireless — ATLAS5010 page 21... -
Page 26: Appendix A Using The Http Interface
Appendix A Command Set Reference Appendix A Using the HTTP Interface Trango Broadband Wireless — ATLAS5010 page 22... -
Page 27: Appendix B Specifications
Temperature Range -40° to 60° C (-40° to 140° F) NEMA Rating NEMA 4 Radio Dimensions 14.5 in. x 14.5 in. x 3.75 in. Radio Weight 7 Lbs. (INT) User Interfaces RJ45 (shielded) Trango Broadband Wireless — ATLAS5010 page 23...
