Appendix A
Model:
Unit Type:
Hardware Version:
Firmware Version:
System Up Time:
MAC:
IP, Subnet Mask, Gateway:
Opmode:
Default Opmode:
Peer ID:
Status:
RSSI:
Tx MIR:
Channel:
Tx Power:
Channel Table:
Area Code:
Auto Rate Shift:
Auto Scan MU:
RSSI LED:
Remarks:
Eth In:
Eth Out:
RF In:
Trango Broadband Wireless — Atlas5010
Model number.
Atlas unit type either MU (master) or RU (remote).
Hardware version is factory-set and can not be changed by user.
Current firmware version loaded in the radio.
Time since radio was last rebooted or powered.
MAC address of the radio.
IP, subnet mask, and gateway of radio
Current operation of the radio.\"On\" indicates transmitting. \"Off\" indicates
not transmitting.
Opmode which radio enters after reboot or power cycle.
User entered MAC address of the peer unit. In the MU, Peer ID is the MAC
address of the RU. In the RU, Peer ID is the MAC address of the MU.
Status of Remote Unit. Connected (wireless link established) or disconnected
(wireless link not established).
Relative Signal Strength Indicator. Displays signal strength received from the
Remote Unit. 'n/a' indicates Remote Unit is not connected.
Transmit Maximum Information Rate to the peer unit.
RF Channel
Transmit power
Set of channels based on the area code setting. Channels which are lined-
out are not available for use based on area code setting.
Country code – defines set of available channels and maximum power
based on regulatory restrictions. Setting can not be changed by user.
See definition in Configuration section
See definition in Configuration section.
See definition in Configuration section.
See definition in Configuration section.
Counter for Ethernet packets which entered via the Ethernet port of the radio.
Counter for Ethernet packets which exited via the Ethernet port of the radio.
Counter for Ethernet packets which entered over-the-air into the radio.
Command Set Reference
.
