Depth is measured from front door handle to back door handle.
The following table contains the Oracle Rack Cabinet 1242 rack specifications:
Requirement
Usable rack units
Height
Width (with side panels)
Depth Model 1242
Weight Model 1242
Maximum dynamic load
†
Depth is measured from front door handle to back door handle.
Related Information
"Preparing for Server Installation" on page 13
■
Rackmount Kit Contents
The following figure shows the Rackmount Kit contents. For instructions on how to install your
server in a four-post rack using the slide-rail and cable management arm options, refer to the
Rackmounting Template.
†
Specification
42
199.8 cm (78.66 inches)
60 cm (23.62 inches)
120 cm (47.24 inches)
150.6 kg (332 lbs)
2215 kg (1004.7 lbs)
Installing the Storage Server Into a Rack
Rackmount Kit Contents
37
