Call Out Description
5

PCIe slot 1

6 PCIe slot 2
7 PCIe slot 3
8 PCIe slot 4
9 PCIe slot 5
10 PCIe slot 6
11

Serial management (SER MGT) RJ-45 serial port

12 Oracle Integrated Lights Out Manager (ILOM) service processor (SP) network management

(NET MGT) RJ-45 10/100/1000BASE-T port

13

Network (NET) 100/1000BASE-T RJ-45 Gigabit Ethernet (GbE) port: NET 0

14

USB 3.0 connector

15

System status LEDs: Locate Button/LED: white; Fault-Service Required: amber; System

OK: green

16 PCIe slot 7
17 PCIe slot 8
18 PCIe slot 9
19 PCIe slot 10
20 PCIe slot 11: Internal HB card
Related Information
"HC Front Panel Features" on page 28
■
"Storage Server Components" on page 25
■
HC Back Panel Features
Storage Server Features and Components 31
