Operation - Climax LM5200 Operating Manual

Operation

To avoid serious personal injury, do not reach inside the machine, and
keep clear of moving parts while it is operating.
For machines with air motors, if the machine stops moving unexpectedly,
lock out the pneumatic safety valve located at the filter lubricator
assembly before performing any troubleshooting.
HPU (Hydraulic Power Unit)
Each HPU will have a control pendant and an E-Stop (Emergency Stop) button on the control
panel cover. Read the manual included with your HPU, and follow the instructions before
operating.
Pre-Start Checks
Before starting the machine always check for the following items:
All energy supplies are OFF.
•
Lines are properly connected.
•
All machine parts are secure.
•
The machine is securely mounted to the work piece.
•
All handles and tools are removed from the machine.
•
Cables and hoses are away from moving machine parts.
•
Hydraulic fluid reservoir is full. (Consult the HPU manual for capacity and specification.)
•
Quick Steps for Operating
• Extend the spindle to touch the surface.
• Take a skim cut to test the settings.
• Check the finish.
• Adjust as necessary.
P/N 66188, Rev. 5
WARNING
CAUTION
Page 53
