8. Connect the chain end to the hoist ring
shackle on the ram (Figure 17 on page
4645).
9. Install the hoist ring shackle on the swivel
base lifting eye (Figure 17 on page 46).
10. Attach one end link of the chain to the
shackle (Figure 17 on page 46). Thread
both shoulder screws into the hoist ring
shackle until the shoulder is seated (Figure
16).
When connecting the chain to the swivel base lifting eye, thread the
shoulder screws completely into the hoist ring shackle. Failure to do so
may cause the shackle/chain connection to fail and allow the ram to slip
or shift, potentially causing death or serious crushing injury.
11. Thread the other end of the chain through the chain support plate (Figure 17 on page
46).
12. Attach the Chain Support Plate to the Slide Block with the supplied rectangle washer
and M12 socket head cap screw (Figure 17 on page 46). Torque to 65 ft-lb (88 Nm).
P/N 66188, Rev. 5
Figure 16. Seated shoulder screws
WARNING
