Climax LM5200 Operating Manual page 60

Application Lubricant
Lead screws -NOOK E-100
spray lube
-NOOK PAG-1
grease
Ball screws THK ball screws –
THK AFG Grease
NOOK ball screws
– NOOK E-900L
Linear & curved THK Rail – THK
rail AFA Grease
CONOCO
PolyTac EP 2
Hydraulic power CASTROL Hyspin
units AWS-46
(summer)
AWS-32 (winter)
Electric motors See vendor
literature
Tapping & Drilling STETCO Tap
Magic XTRA-
FOAMY
Cutting Oil CONOCO AW 32
* If an approved lubricant cannot be used, contact Climax for an equivalent alternative.
Lubrication for THK Railing
THK, manufacturer of the rail assembly, recommends the rail block be lubricated every 65
hours of operating time with 2.6cc of AFA grease.
Use of other lubricants on THK products will void manufacturer's
warranty.
4 Use of other lubricants on THK products will void manufacturer's warranty.
5 Always replace hydraulic filters when replacing hydraulic oil. Never assume that oil in drums is clean, always pump
oil through a 5 micron hydraulic filter before/while filling reservoir.
Page 58
Biodegradable
Lubricant
CASTROL BioTac
EP 2
N/A
CASTROL BioTac
EP 2
N/A
4
CASTROL BioTac
EP 2
CASTROL BioBar
46 (summer); 32
(winter)
N/A
-STETCO Tap
Magic Protap
-Chesterton 388
CONOCO Ecoterra
32
IMPORTANT
Viscosity
Quantity
(cSt)
96 @ 40C Light coating
11.3 @ 100C applied by
hand
Not Available Sizes < 32
mm use 0.16
cc per nut
Not Available
Sizes >=32
mm use 0.24
cc per nut
32 @ 40C Sizes <35
use 0.16 cc
per bearing
block
129 @ 40C
Sizes >=35
11.6 @ 100C
use 0.24 cc
per bearing
block
46 @ 40C As required to
6.82 @ 100C fill reservoir to
mid-sight
glass level
32 @ 40C
5.44 @ 100C
N/A See vendor
literature
Not Available As required
32 @ 40C As required
5.44 @ 100C
LM5200 Operating Manual
Frequency
Weekly during
machine use
1x per use or
weekly for
continued use
1x per use or
weekly for
continued use
Refill every use.
Replace oil every 2
years 5
See vendor
literature
Per hole tapped or
drilled
Continued use
while cutting
