Trane SCWM Series Installation, Operation And Maintenance Manual page 22

Weights
Table 12. Unit shipping weights (starter cassette)
Tonnage Overall dimensions
40 Ton 70"x 84" x 95.5"
50 Ton 70"x 84" x 95.5"
60 Ton 70"x 84" x 95.5"
70 Ton 70"x 84" x 126"
80 Ton 70"x 84" x 126"
Table 13. Unit shipping weights (evaporator cassette)
Tonnage Overall dimensions
40 Ton 70"x 84" x 95.5"
50 Ton 70"x 84" x 95.5"
60 Ton 70"x 84" x 95.5"
70 Ton 70"x 84" x 126"
80 Ton 70"x 84" x 126"
22
Unit Weight
Starter Cassette
(lbs)
2933 34.5"x 54.5"x 27.6"
3365 34.5"x 54.5"x 27.6"
3500 34.5"x 54.5"x 27.6"
4545 34.5"x 54.5"x 27.6"
4545 34.5"x 54.5"x 27.6"
Unit Weight
Evaporator Cassette
(lbs)
2933 34.5"x 84"x 94"
3365 34.5"x 84"x 94"
3500 34.5"x 84"x 94"
4545 34.5"x 84"x 126"
4545 34.5"x 84"x 126"
Starter Cassette Weight
(230 VAC)
323
323
323
388
388
Total Weight of Cassette
(exc. Economizer)
1127
1219
1254
1651
1651
