9.
Install the serial port cable.
10. Connect the serial port cable to the M.2 SSD/dedicated iLO/serial port enablement board.
11. Install the riser cage.
12. Install the access panel.
13. Install the server into the rack.
14. Connect all peripheral cables to the server.
15. Connect the power cords:
a. Connect each power cord to the server.
b. Connect each power cord to the power source.
16. Power up the server.
17. If removed, install the security bezel.
The installation is complete.

Enabling the dedicated iLO management module

The onboard NIC 1/shared iLO connector is set as the default system iLO connector. To enable the dedicated iLO
management module, use the iLO 5 Configuration Utility accessible within the HPE UEFI System Utilities.
For more information on the UEFI System Utilities, see the UEFI documentation on the Hewlett Packard Enterprise
website (http://www.hpe.com/servers/uefi).
IMPORTANT: If the iLO configuration settings are reset to the default values, remote access to the machine will be
lost. Access the physical machine and repeat the procedure described in this section to re-enable the dedicated iLO
management connector.
Procedure
1. During the server startup sequence after installing the module, press F9 in the POST screen.
