AXIOMTEK SBC8241 User Manual page 36

Floppy Disk Connector: CN2
Pin Description
1 GND
GND
3
GND
5
GND
7
GND
9
11 GND
13 GND
15 GND
17 GND
19 GND
GND
21
GND
23
GND
25
27 GND
29 GND
31 GND
33 GND
Keylock/Power LED: CN11

('
SBC8241 486 All-in-One Half-size User's Manual
Pin
2 Reduce write current
N.C.
4
N.C.
6
Index #
8
Motor enable A#
10
12 Drive select B#
14 Drive select A#
16 Motor enable B#
18 Direction #
20 STEP#
Write data #
22
Write gate #
24
Track 0#
26
28 Write protect #
30 Read data #
32 Side 1 select #
34 Disk change #
Pin Description
1 Power LED +
N.C.
2
Power LED - / GND
3
Keyboard lock
4
5 Power LED - / GND
Description


Pin Assignments
