Installing The Autosampler - PerkinElmer AVIO 200 Hardware Manual

Installation
Figure 4-31
Item
1
2
3

Installing The Autosampler

The instrument can be used with the PerkinElmer S10 Autosamplers. The following
procedures describe the electrical connections necessary to install the PerkinElmer
autosamplers.
After the autosampler is installed, the software must be configured for the type of
autosampler you are using. This can be done during the software installation or, in
the ICP software, by selecting the Configure Autosampler command from the
System menu. See the S10 Autosampler User's Guide (Part No. 09931133) for
detailed information on installing the autosampler.
142
1
3
Locking Into Position
Latch Closed
Locking Pin
Inner Adjustment Plate in Place
2
Description
