Technical Data

ELECTRICAL DATA
Power supply
Input voltage
Frequency
Protections (optional)
Overvoltage protection
(optional)
Protections may not be included in the charge point, at this
point, protections with the same characteristics, shall be placed
upstream. The national regulations must be taken into account.
MODEL* CONNECTORS*
S Type 2 Cable
T Type 2 Socket
(**) Minimun cable section recommended for the maximum AC input current, the final section must be
calculated by a qualified technician taking into account the specific conditions of the installation.
1P+N+PE / 3P+N+PE
230VAC+/- 10% / 400VAC+/-10%
50Hz / 60Hz
MCB (curve C) - includes shunt trip
Leakage detector (MCB/RCBO with shunt trip is
required to open the circuit)
RCBO: RCD Type A (S) + MCB (S) - includes shunt trip
Transient surge protector
IEC 61643-1 (Class II)
OUTPUT
CURRENT
32A
32A
(*) Please consult the availability to your local supplier
MINIMUM
OUTPUT
CABLE CROSS-
POWER
-SECTION**
7,4kW 10mm
22kW 10mm
2
2
