LSI LSI8751SP User Manual

Pci to ultra scsi host adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S
GUIDE
LSI8751SP
PCI to Ultra SCSI
Host Adapter
Version 2.1
N o v e m b e r 2 0 0 0
®
S14016.A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSI8751SP and is the answer not in the manual?

Questions and answers

Related Manuals for LSI LSI8751SP

Summary of Contents for LSI LSI8751SP

  • Page 1 USER’S GUIDE LSI8751SP PCI to Ultra SCSI Host Adapter Version 2.1 N o v e m b e r 2 0 0 0 ® S14016.A...

  • Page 2: Electromagnetic Compatibility Notices

    Consult the dealer or an experienced radio/TV technician for help. Shielded cables for SCSI connection external to the cabinet are used in the compliance testing of this Product. LSI Logic is not responsible for any radio or television interference caused by unauthorized modification of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by LSI Logic.
  • Page 3 LSI Logic; nor does the purchase or use of a product from LSI Logic convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Logic or third parties.
  • Page 5 Preface This book is the primary reference and user’s guide for the LSI Logic LSI8751SP PCI to Ultra SCSI Host Adapter. It contains a complete functional description for the LSI8751SP and includes complete physical and electrical specifications for the LSI8751SP.
  • Page 6 Related Publications PCI Storage Device Management System SDMS 4.0 User’s Guide, Order Number S14007.A Revision Record Revision Date Remarks 6/95 Final version. 5/99 Document converted to LSI format. 11/00 All product names changed from SYM to LSI. Preface...

  • Page 7: Table Of Contents

    Contents Chapter 1 Using the LSI8751SP General Description Features 1.2.1 PCI Interface 1.2.2 SCSI Interface 1.2.3 Board Characteristics Interface Descriptions 1.3.1 The PCI Interface 1.3.2 The SCSI Interface 1.3.3 Ultra SCSI Chapter 2 Installing the LSI8751SP Quick Installation Procedure Detailed Installation Procedure 2.2.1...
  • Page 8 Chapter 3 Configuring the LSI8751SP When to Configure the LSI8751SP Starting the SCSI BIOS Configuration Utility 3.2.1 Configuration Utility Main Menu 3.2.2 Utilities Menu 3.2.3 Device Selections Menu 3-11 Exiting the SCSI BIOS Configuration Utility 3-14 Appendix A Technical Specifications Physical Environment A.1.1...
  • Page 9 Boot Order Menu Adapter Configuration Menu Utilities Menu Adapter Setup Menu Device Selections Menu 3-11 Device Selections Menu (Cont.) 3-12 LSI8751SP Mechanical Drawing Tables SCSI ID Record 2-25 Global Default Settings Device Default Settings Maximum Power Requirements PCI Connector J1 (Top)
  • Page 10 Contents...

  • Page 11: Chapter 1 Using The Lsi8751Sp

    Chapter 1 Using the LSI8751SP This chapter describes the LSI8751SP PCI to Ultra SCSI Host Adapter interface to PCI computer systems and includes these topics: • Section 1.1, “General Description,” page 1-1 • Section 1.2, “Features,” page 1-2 • Section 1.3, “Interface Descriptions,” page 1-3 1.1 General Description...

  • Page 12: Features

    1.2 Features This section provides a high level overview of the PCI Interface, the SCSI Interface, and Board Characteristics for the LSI8751SP. 1.2.1 PCI Interface • Full 32-bit DMA bus master • Zero wait-state bus master data bursts • Universal PCI bus voltage support 1.2.2 SCSI Interface...

  • Page 13: Interface Descriptions

    SCSI bus and generates timing and protocol in compliance with the SCSI standard. The SCSI interface on the LSI8751SP operates as 8-bit or 16-bit, synchronous or asynchronous, SE bus, and supports Ultra SCSI protocols and 16-bit arbitration. The interface is made through two (and only two) of the connectors J2, J3,s and J4.

  • Page 14: Ultra Scsi

    A 40 MHz oscillator is installed on the LSI8751SP to provide the clock frequency to the LSI53C875J that is necessary to support Wide Fast-20 SCSI transfers of up to 40 Mbytes/s. 1.3.3 Ultra SCSI The LSI8751SP fully supports Ultra SCSI as well as Fast SCSI simultaneously.

  • Page 15: Chapter 2 Installing The Lsi8751Sp

    Chapter 2 Installing the LSI8751SP This chapter provides instructions on how to install the LSI8751SP and includes these topics: • Section 2.1, “Quick Installation Procedure,” page 2-1 • Section 2.2, “Detailed Installation Procedure,” page 2-3 • Section 2.3, “Completing the Installation,” page 2-26 2.1 Quick Installation Procedure...
  • Page 16 Step 4. Locate the slot for installing a PCI plug-in board. The LSI8751SP requires a PCI slot which allows bus master operation. Step 5. Remove the blank bracket panel on the back of the computer aligned with the PCI slot you intend to use. Save the bracket screw.

  • Page 17: Detailed Installation Procedure

    2.2 Detailed Installation Procedure This section provides step-by-step instructions for installing the LSI8751SP, and connecting it to your SCSI peripherals. If you are experienced in these tasks, you may prefer to use the preceding Section 2.1, “Quick Installation Procedure.” If you are not confident that you can perform the tasks as described here, LSI Logic suggests getting assistance.

  • Page 18: Inserting The Host Adapter

    Step 1. Ground yourself before removing this host adapter board. Remove the LSI8751SP from the packing and check that it is not damaged. An example of this host adapter board is shown Figure 2.1.
  • Page 19 Figure 2.1 Hardware Connections for the LSI8751SP 68-pin Internal High Density SCSI Interface Connector 68-pin External High Density SCSI Interface J1 to PCI Bus Connector on Mainboard WARNING: Never use more than two connectors simultaneously. Step 6. Carefully insert edge connector J1 (see Figure 2.1) of the host...

  • Page 20: Inserting The Host Adapter

    Step 7. The bracket around the connector J3 (see Figure 2.1) should fit where you removed the blank panel. Secure it with the bracket screw (see Figure 2.2) before making the internal and external SCSI bus connections. Installing the LSI8751SP...

  • Page 21: Connecting The Scsi Peripherals

    2.2.3 Connecting the SCSI Peripherals Internal SCSI bus connections to the LSI8751SP are made with an unshielded, 68 or 50-conductor ribbon cable (see Figure 2.3). One edge of this cable is marked with a color to indicate the pin-1 side. Sometimes the connectors on this cable are keyed to ensure proper pin-1 connection.
  • Page 22 3-meter Ultra SCSI cable (0.75 m between devices). The SE SCSI bus should not exceed 3 meters (total internal and external cable lengths), even with fewer than four devices. The two internal cables come in the LSI8751SP kit. Installing the LSI8751SP...

  • Page 23: Making Internal Scsi Bus Connections

    2.2.4 Making Internal SCSI Bus Connections This section provides step-by-step instructions about making internal SCSI bus connections. Step 1. If you are connecting an internal Wide SCSI device, plug the 68-pin connector on one end of a wide internal SCSI ribbon cable into the connector J2 (see Figure 2.4).

  • Page 24: Internal Scsi Ribbon Cable To Host Adapter Connection

    8-bit internal SCSI ribbon cable into the connector J4 (see Figure 2.5). Make certain to match pin 1 on both connectors. Figure 2.5 Internal SCSI Ribbon Cable to Host Adapter Connection 2-10 Installing the LSI8751SP...

  • Page 25: Internal Scsi Ribbon Cable To Internal Scsi Device

    Step 3. Plug the 68 or 50-pin connector on the other end of the internal SCSI ribbon cable into the SCSI connector on your internal SCSI device. An example of this connection is shown in Figure 2.6. Make sure to match pin 1 on all connections. Figure 2.6 Internal SCSI Ribbon Cable to Internal SCSI Device Connection...
  • Page 26 Figure 2.7. An example of this type of a chained connection is shown in Figure 2.8. Make sure to match pin 1 on all connections. Figure 2.7 Connection Additional Internal SCSI Devices 2-12 Installing the LSI8751SP...

  • Page 27: Multiple Internal Scsi Devices Chained Together

    Figure 2.8 Multiple Internal SCSI Devices Chained Together Detailed Installation Procedure 2-13...

  • Page 28: Using Both Internal Connectors

    Step 5. It is also possible to use both internal connectors (J2 and J4) if you do not attach any external devices to connector J3. An example of this configuration is shown in Figure 2.9. Figure 2.9 Using Both Internal Connectors 2-14 Installing the LSI8751SP...

  • Page 29: Scsi Led Connector

    Step 6. Most PC cabinets are designed with a front panel LED (sometimes already connected to an existing IDE drive). Connect the LED cable to connector J5 on your host adapter, as shown in Figure 2.10. This connection causes the front panel LED to indicate activity on the SCSI bus.

  • Page 30: Making External Scsi Bus Connections

    2.2.5 Making External SCSI Bus Connections This section provides step-by-step instructions about making external SCSI bus connections. Step 1. If you need to connect external SCSI devices to the LSI8751SP, plug the 68-pin connector on one end of a shielded external SCSI cable (see Figure 2.3) into the host adapter connector J3...

  • Page 31: External Cable To External Scsi Device

    Step 2. Plug the 68-pin connector on the other end of the shielded external SCSI cable into the SCSI connector on your external SCSI device. An example of this connection is shown in Figure 2.12. Figure 2.12 External Cable to External SCSI Device Detailed Installation Procedure 2-17...

  • Page 32: Multiple External Scsi Devices Chained Together

    Step 3. If you wish to connect more than one external SCSI device to your host adapter, you must chain them together with shielded external SCSI cables. An example of these chained connections is shown in Figure 2.13. Figure 2.13 Multiple External SCSI Devices Chained Together 2-18 Installing the LSI8751SP...

  • Page 33: Scsi Bus Termination

    SCSI bus must have their terminators active. All other SCSI devices on the bus must have their terminators removed or disabled. Remember that your LSI8751SP is also on the SCSI bus—its termination is automatically enabled when it is connected to the end of the bus.

  • Page 34: Internal Scsi Connections

    SCSI bus configuration. Figure 2.14 Internal SCSI Device Termination Last Device on Chain – Termination Enabled Does Not End Chain – Termination Disabled Host Adapter Automatically Terminated 2-20 Installing the LSI8751SP...

  • Page 35: External Scsi Connections

    2.2.8 External SCSI Connections If you have only external SCSI device connections to your host adapter, you must terminate the last external device on the SCSI bus. You must disable the termination on all other devices. Termination on your host adapter is automatically enabled in this case.

  • Page 36: Internal And External Scsi Connections

    SCSI bus configuration. Figure 2.16 Internal and External SCSI Device Termination Last Device on Chain – Termination Enabled Host Adapter Does Not Termination End Chain – Automatically Termination Disabled Disabled Last Device on Chain – Termination Enabled 2-22 Installing the LSI8751SP...

  • Page 37: Internal Scsi Connections For Both Internal Connectors

    2.2.10 Internal SCSI Connections for Both Internal Connectors If you have made internal SCSI device connections to both internal connectors (J2 and J4) on the host adapter, you must terminate the internal devices on each end of the SCSI bus. You must disable the termination on all other devices.

  • Page 38: Setting Scsi Ids

    Chapter 3, “Configuring the LSI8751SP,” explains how to set your host adapter ID using the LSI Logic SCSI BIOS Configuration Utility. Your peripheral device SCSI IDs are usually set with jumpers or with a switch on the peripheral. Refer to the peripheral manufacturer’s instructions and to the user’s manual for your computer to determine the...

  • Page 39: Scsi Id Record

    Table 2.1 SCSI ID Record SCSI ID SCSI Device LSI8751SP (default) Detailed Installation Procedure 2-25...

  • Page 40: Completing The Installation

    Step 3. Wait for your computer to boot up. Step 4. To change the configuration of your host adapter, see Chapter 3, “Configuring the LSI8751SP.” Finally, refer to the PCI Storage Device Management System SDMS 4.0 User’s Guide (or the guide for the software you use) to load the driver software for your particular operating system.

  • Page 41: Chapter 3 Configuring The Lsi8751Sp

    Chapter 3 Configuring the LSI8751SP This chapter describes configuring the LSI8751SP and includes these topics: • Section 3.1, “When to Configure the LSI8751SP,” page 3-1 • Section 3.2, “Starting the SCSI BIOS Configuration Utility,” page 3-2 • Section 3.3, “Exiting the SCSI BIOS Configuration Utility,” page 3-14 3.1 When to Configure the LSI8751SP...

  • Page 42: Starting The Scsi Bios Configuration Utility

    1. Logical Unit Number. 3.2 Starting the SCSI BIOS Configuration Utility If you have LSI Logic SCSI BIOS Version 4.xx, and it includes the LSI Logic SCSI BIOS Configuration Utility, you can change the default configuration of the SCSI host adapters. You may decide to alter these default values if there is a conflict between device settings or if you need to optimize system performance.

  • Page 43: Configuration Utility Main Menu

    3.2.1 Configuration Utility Main Menu When you start the LSI Logic SCSI BIOS Configuration Utility, the Main Menu appears. This menu displays a list of up to four LSI Logic PCI to SCSI host adapters and information about each of them. To select an adapter, use only the arrow keys and enter key.

  • Page 44: Main Menu

    Below the list of host adapters on the Main Menu display, you see eight options. They are described in detail below. If these settings are altered, the system reboots upon exit from the Configuration Utility by using the Quit option. Configuring the LSI8751SP...

  • Page 45: Change Status On Next Boot Menu

    3.2.1.2 Adapter Boot Order Adapter Boot Order allows the user to set the order in which host adapters will boot when you have more than one LSI Logic host adapter in your system. When this option is selected, the Boot Order menu appears.

  • Page 46: Adapter Configuration Menu

    3.2.1.5 Mono/Color Mono/Color allows the user to choose between a monochrome or color display for the SCSI BIOS Configuration Utility. If needed, choose the mono setting to get a more readable screen on a monochrome monitor. Configuring the LSI8751SP...

  • Page 47: Utilities Menu

    3.2.1.6 Language If enabled, the Language option allows the user to select from five languages for the Configuration Utility: English, German, French, Italian, and Spanish. Call for support if you have any additional questions. 3.2.1.7 Help The Help option displays a help screen with information about the Main Menu.

  • Page 48: Adapter Setup Menu

    SCSI devices attached to it. One of these choices can be selected by highlighting it and pressing Enter. SCAM Support – The LSI Logic BIOS Version 4.xx and above supports the SCSI Plug and Play protocol called SCAM. SCAM support by default is off in versions 4.09 and later for the LSI53C875 device.
  • Page 49 Parity – The LSI Logic PCI to SCSI host adapters always generate parity, but some older SCSI devices do not. Therefore, you are offered the option of disabling parity checking. Note: When disabling parity checking, it is also necessary to disable disconnects for all devices, as parity checking for the reselection phase is not disabled.
  • Page 50 Spinup Delay (seconds) – This option allows you to stagger spinups for a longer period of time to balance the total current load. The default value is 2 seconds with choices between 1 and 10 seconds. 3-10 Configuring the LSI8751SP...

  • Page 51: Device Selections Menu

    This is a power management device designed to accommodate disk devices that may have heavy current load during power up. If multiple drives are being powered up simultaneously and drawing heavy current loads, then this option staggers the spinups to limit startup current. 3.2.3 Device Selections Menu When you select the Device Selections option, the corresponding menu (as shown in...

  • Page 52: Device Selections Menu (Cont.)

    I/O processes. Additionally, it tells the host adapter whether or not to allow a device to disconnect. Some devices run faster with disconnects enabled (typically newer devices), while some run faster with disconnects disabled (typically older devices). 3-12 Configuring the LSI8751SP...
  • Page 53 Read/Write I/O Time-out (seconds) – This option sets the amount of time the host adapter waits for a read, write, or seek command to complete before trying the I/O transfer again. Since this provides a safeguard allowing the system to recover if an I/O operation fails, it is recommended that you always set the time-out to a value greater than zero.

  • Page 54: Exiting The Scsi Bios Configuration Utility

    Configuration Utility properly. Return to the Main Menu and exit by using the Quit option. Important: Rebooting the system without properly exiting from this utility may cause some changes to not take effect. 3-14 Configuring the LSI8751SP...

  • Page 55: Appendix A Technical Specifications

    FCC. A.1.1 Physical Characteristics The dimensions of the LSI8751SP are 127 x 82.55 mm (5.00 x 3.25 inches). PCI connection is made through edge connector J1. Internal 16-bit SCSI connection is made through the 68-pin high density connector J2.

  • Page 56: Electrical Characteristics

    127.00 (REF) (5.00 (REF)) LSI53C875J All dimensions are given in mm and (inches). A.1.2 Electrical Characteristics The LSI8751SP maximum power requirements, including SCSI TERMPWR, under normal operation are as follows: Table A.1 Maximum Power Requirements Over the operating range 5–55 ° C ±...

  • Page 57: Thermal, Atmospheric Characteristics

    PCI bus slot, all voltages are below the SELV 42.4 V limit. A.2 Operational Environment The LSI8751SP is designed for use in PCI computer systems with an ISA/EISA bracket type. The SDMS software operates the board, but the design of the board does not prevent the use of other software.

  • Page 58: Pci Connector J1 (Top

    these 3.3 V pins is used on the board. The PCI portion of the LSI53C875J chip is powered from the 3 V/5 V pins. Table A.2 PCI Connector J1 (Top) Signal Name Signal Name Signal Name − 12 V +3.3 V AD27 C_BE1/ AD25...

  • Page 59: Pci Connector J1 (Bottom

    Table A.3 PCI Connector J1 (Bottom) Signal Name Signal Name Signal Name TRST/ AD28 +12 V AD26 AD15 +3.3 V AD24 AD13 +5 V IDSEL AD11 INTA/ +3.3 V INTC/ AD22 AD09 +5 V AD20 KEYWAY RESERVED KEYWAY 3 V/5 V AD18 C_BE0/ RESERVED...

  • Page 60: The Scsi Interface

    A.2.2 The SCSI Interface The SCSI interface operates as 16-bit, synchronous or asynchronous, SE bus, and supports SCSI-3 protocols and 16-bit arbitration. The interface is made through connectors J2, J3, and J4. Connector J2 is a 68-pin high density right angle receptacle used for internal connections (16-bit SCSI).

  • Page 61: Scsi Connectors J3 And J4

    Table A.4 SCSI Connectors J3 and J4 Signal Name Signal Name Signal Name SD7/ SDP/ CPRSNT_A-B/ TERMPWR TERMPWR SATN/ SBSY/ SD12/ SACK/ SD13/ SRST/ SD14/ SMSG/ SD15/ SSEL/ SDP1/ SC_D/ TERMPWR SD0/ SREQ/ TERMPWR SD1/ SI_O/ SD2/ SD8/ SD3/ SD9/ SD4/ SD10/ SD5/...

  • Page 62: Scsi Connector J2

    Table A.5 SCSI Connector J2 Signal Name Signal Name SD0/ SD1/ SD2/ SD3/ SD4/ SD5/ SD6/ SD7/ SDP/ CPRSNT_C/ TERMPWR SATN/ SBSY/ SACK/ SRST/ SMSG/ SSEL/ SC_D/ SREQ/ SI_O/ CPRSNT_C/ is used to sense the connection of a standard SCSI device by sensing SCSI standard GND on this pin.

  • Page 63: The Led Interface

    GPIO0_FETCH line (maximum output low voltage 0.4 V and minimum output low current 16 mA) is pulled low to complete the circuit when a harness with an LED is attached. The connector on the LSI8751SP is J5. Table A.6 LED Connector J5...
