USER'S
GUIDE
LSI21002 PCI to
Dual Channel SCSI
Host Adapter
Version 1.1
N o v e m b e r 2 0 0 0
®
S14001.A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSI21002 and is the answer not in the manual?

Questions and answers

Related Manuals for LSI LSI21002

Summary of Contents for LSI LSI21002

  • Page 1 USER’S GUIDE LSI21002 PCI to Dual Channel SCSI Host Adapter Version 1.1 N o v e m b e r 2 0 0 0 ® S14001.A...

  • Page 2: Electromagnetic Compatibility Notices

    Consult the dealer or an experienced radio/TV technician for help. Shielded cables for SCSI connection external to the cabinet are used in the compliance testing of this Product. LSI Logic is not responsible for any radio or television interference caused by unauthorized modification of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by LSI Logic.
  • Page 3 LSI Logic; nor does the purchase or use of a product from LSI Logic convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Logic or third parties.
  • Page 5 Preface This book is the primary reference and user’s guide for the LSI Logic LSI21002 PCI to Dual Channel SCSI Host Adapter. It describes how to install and configure the LSI21002 host adapter board in a PCI computer system. Basic information on setting up the SCSI bus is also provided.
  • Page 6 Glossary, provides definitions of various terminology that is referenced throughout this user’s guide. Related Publications PCI Storage Device Management System SDMS 4.0 User’s Guide, Order Number S14007.A Revision Record Revision Date Remarks 3/99 Final version. 11/00 All product names changed from SYM to LSI. Preface...

  • Page 7: Table Of Contents

    Setting Interrupts (Exceptional Cases) 2-24 Completing the Installation 2-25 Chapter 3 Configuring the Host Adapter When to Configure the LSI21002 Starting the SCSI BIOS Configuration Utility 3.2.1 Configuration Utility Main Menu 3.2.2 Utilities Menu Exiting the SCSI BIOS Configuration Utility...
  • Page 8 The SCSI Interface Appendix B Glossary Index Customer Feedback Figures Hardware Connections for the LSI21002 Inserting the Host Adapter SCSI Cables Internal SCSI Ribbon Cable to Host Adapter Internal SCSI Ribbon Cable to Internal SCSI Device Connection Connecting Additional Internal SCSI Devices...
  • Page 9 Change Status on Next Boot Menu Boot Order Menu Adapter Configuration Menu Utilities Menu Adapter Setup Menu Device Selections Menu 3-11 Device Selections Menu (Cont.) 3-12 LSI21002 Mechanical Drawing Tables Standard Cables SCSI ID Record 2-23 Setting Interrupts 2-24 Global Default Settings Device Default Settings...
  • Page 10 Contents...

  • Page 11: Chapter 1 Using The Lsi21002

    The LSI21002 provides internal and external SCSI interfaces to PCI computer systems that require BIOS support on the add-in SCSI adapter. It will be referred to as the LSI21002 throughout this manual. Installing the LSI21002 in your PCI system allows connection of SCSI devices over a SCSI bus.

  • Page 12: Features

    1.2 Features This section provides a high level overview of the PCI Interface, the SCSI Interface, and Board Characteristics for the LSI21002. 1.2.1 PCI Interface • True PCI multifunction controller for maximum performance • 32-bit (33 MHz) DMA bus master •...

  • Page 13: Board Characteristics

    • Supports SE and LVD signaling with automatic termination – Channel A is SE only with autosense termination – Channel B is SE or LVD with termination permanently enabled • Performs complex bus sequences without interrupts, including restore data pointers •...

  • Page 14: Interface Descriptions

    PCI is a high-speed standard local bus for interfacing a number of I/O components to a PC processor and memory subsystem. The PCI functionality for the LSI21002 is contained within the LSI53C896 PCI Dual Channel SCSI Multifunction Controller. The LSI53C896 connects directly to the PCI bus and generates timing protocol in compliance with the PCI specification.

  • Page 15: Scsi Activity Led Interface

    1.5 A short circuit protection device. An on-board LED lights up when TERMPWR is shorted and has turned off. A 40 MHz oscillator is installed on the LSI21002 to provide the clock frequency to the LSI53C896 that is necessary to support SCSI transfers.

  • Page 16: Standard Cables

    However, if any device on the bus is SE only, then the entire bus switches to SE mode, and the distances in the SE column apply. 3. SE and high power differential are not defined at Ultra2 speeds. Using the LSI21002...

  • Page 17: Chapter 2 Installing The Lsi21002

    Step 1. Before proceeding, ground yourself so that a static discharge does not damage the board. Remove the LSI21002 from the packing and check that it is not damaged. An example of this...
  • Page 18 The use of a static ground strap is recommended. Step 4. Locate the slots for the PCI plug-in board installation. A 32-bit slot should be used. The LSI21002 will work in a 64-bit slot, but only 32 bits are used. The LSI21002 requires a PCI slot that allows bus master operation.

  • Page 19: Detailed Installation Procedure

    2.2 Detailed Installation Procedure This section provides step-by-step instructions for installing your LSI21002 and connecting it to your SCSI peripherals. If you are experienced in these tasks, you may prefer to use Section 2.1, “Quick Installation Procedure.”...

  • Page 20: Inserting The Host Adapter

    Step 4. Locate the slots for the PCI plug-in board installation. A 32-bit slot should be used. The LSI21002 will work in a 64-bit slot, but only 32 bits are used. The LSI21002 requires a PCI slot that allows bus master operation. See Figure 2.2.

  • Page 21: Hardware Connections For The Lsi21002

    Secure it with the bracket screw (see Figure 2.2) before making the internal and external SCSI bus connections. Figure 2.1 Hardware Connections for the LSI21002 Channel B 68-Pin Internal High Density SCSI Connector J5 Channel A 68-Pin...

  • Page 22: Connecting The Scsi Peripherals

    Bracket Screw 32-bit Slot 64-bit Slots 2.2.3 Connecting the SCSI Peripherals All internal SCSI bus connections to the LSI21002 are made with an unshielded, 68- or 50-conductor ribbon cable (see Figure 2.3). One side of this cable is marked with a color to indicate the pin-1 side. The connectors on this cable are keyed to ensure a proper pin-1 connection.

  • Page 23: Scsi Cables

    For convenience, Channel A also has a 50-pin narrow (ribbon) connector. Some internal cables come with an SE/LVD terminator on one end. This end should be furthest from the host adapter. All external SCSI bus connections to the LSI21002 are made with a shielded, 50-pin high density cable (see Figure 2.3).

  • Page 24: Internal Scsi Ribbon Cable To Host Adapter

    Step 1. To connect an internal SCSI device, plug the 68-pin connector end of a wide internal SCSI ribbon cable into connector J2 or J5. See the example in Figure 2.4. Figure 2.4 Internal SCSI Ribbon Cable to Host Adapter Installing the LSI21002...

  • Page 25: Internal Scsi Ribbon Cable To Internal Scsi Device Connection

    Step 2. Plug the 68-pin connector on the other end of the wide internal SCSI ribbon cable into the SCSI connector on the internal SCSI device. Pin 1 must match on all connections. An example of this connection appears in Figure 2.5.
  • Page 26 Step 3. To plug in additional internal SCSI devices, use an internal SCSI ribbon cable with the required number of connectors attached along its length. See the example in Figure 2.6. Figure 2.6 Connecting Additional Internal SCSI Devices 2-10 Installing the LSI21002...
  • Page 27 An example of multiple internal SCSI devices chained together is shown in Figure 2.7. Make sure to match pin 1 on all connections. Figure 2.7 Multiple Internal SCSI Devices Chained Together Detailed Installation Procedure 2-11...
  • Page 28 J6. If the LED does not light during SCSI bus activity from this host adapter, you may have to rotate the LED connector 180 ° on J6. Table A.7 Appendix A for connector pinout information. Figure 2.8 SCSI LED Connector 2-12 Installing the LSI21002...

  • Page 29: External Cable To Host Adapter

    2.2.3.2 Making External SCSI Bus Connections This section provides step-by-step instructions about making external SCSI bus connections: Step 1. To connect external SCSI devices to the LSI21002, plug the 50-pin high density connector on one end of a shielded external high density cable (see Figure 2.3) into the host adapter...

  • Page 30: External Cable To External Scsi Device

    Step 2. Plug the 50-pin high density connector on the other end of the shielded external SCSI cable into the SCSI connector on the external SCSI device. An example of this connection is shown Figure 2.10. Figure 2.10 External Cable to External SCSI Device 2-14 Installing the LSI21002...

  • Page 31: Scsi Bus Termination

    Step 3. To connect more than one external SCSI device to the host adapter, chain them together with shielded external SCSI cables. See the example in Figure 2.11. Figure 2.11 Multiple External SCSI Devices Chained Together 2.2.4 SCSI Bus Termination The devices that make up the SCSI bus are connected serially (chained together) with SCSI cables.
  • Page 32 Remember: The LSI21002 is also on the SCSI bus, and its termination is automatically enabled when it is connected to the end of the bus. LVD peripheral devices are normally terminated with external terminators, but are sometimes set with jumpers or with a switch on the peripheral.

  • Page 33: Internal Scsi Device Termination

    is automatically enabled for Channel A. The termination for Channel B is enabled all the time. Figure 2.12 shows an example of how termination is determined for this SCSI bus configuration. Figure 2.12 Internal SCSI Device Termination Detailed Installation Procedure 2-17...

  • Page 34: External Scsi Device Termination

    SCSI bus configuration on the host adapter external Channel A. Figure 2.13 External SCSI Device Termination Last Device on Chain – Termination Enabled Does Not End Chain – Termination Disabled Host Adapter Automatically Terminated 2-18 Installing the LSI21002...
  • Page 35 2.2.4.3 Internal and External SCSI Connections If internal and external SCSI devices are connected to the host adapter, then terminate the last internal and external devices on the SCSI bus. You must disable the termination on all other devices. Termination on Channel A of the host adapter is automatically disabled in this case.

  • Page 36: Internal And External Scsi Device Termination

    Figure 2.14 Internal and External SCSI Device Termination Last Device on Chain – Termination Enabled Does Not End Chain – Termination Disabled Last Device on Chain – Termination Enabled 2-20 Installing the LSI21002...
  • Page 37 2.2.4.4 Internal SCSI Connections for both Internal Connectors If internal SCSI device connections to both internal connectors (J2 and J4) on your host adapter have been made, then terminate the internal devices on each end of the SCSI bus. You must disable the termination on all other devices.
  • Page 38 Host Adapter," explains how to set the host adapter ID using the LSI Logic SCSI BIOS Configuration Utility. The peripheral device SCSI IDs are usually set with jumpers or with a switch on the peripheral. Refer to the peripheral manufacturer’s instructions and to the user’s manual for your computer to determine the...

  • Page 39: Scsi Id Record

    Make any necessary changes to the SCSI IDs and record the IDs for future reference. Table 2.1 is provided as a place to keep this record. Table 2.1 SCSI ID Record SCSI ID SCSI Device Channel A SCSI Device Channel B LSI21002 (default) LSI21002 (default) Detailed Installation Procedure 2-23...

  • Page 40: Setting Interrupts (Exceptional Cases)

    This capability requires enabling the INTA/INTB/ to act as a jumper for special configuration purposes. This feature is not packaged with the standard LSI21002, as the default interrupt routing is sufficient for most systems. In the exceptional case, where a user would require jumper settings, Table 2.2...

  • Page 41: Completing The Installation

    2.4 Completing the Installation Before replacing the cover on your computer, review this installation procedure check list. This can save you effort later. Verify Installation Procedures Done Host adapter connection in PCI bus slot secure Internal SCSI bus connections secure (pin-1 continuity) External SCSI bus connections secure Proper SCSI bus termination established Unique SCSI IDs set and recorded for each device...
  • Page 42 2-26 Installing the LSI21002...

  • Page 43: Chapter 3 Configuring The Host Adapter

    Chapter 3 Configuring the Host Adapter This chapter describes configuring the LSI21002 and includes these topics: • Section 3.1, “When to Configure the LSI21002,” page 3-1 • Section 3.2, “Starting the SCSI BIOS Configuration Utility,” page 3-2 • Section 3.3, “Exiting the SCSI BIOS Configuration Utility,” page 3-14 3.1 When to Configure the LSI21002...

  • Page 44: Starting The Scsi Bios Configuration Utility

    Queue Tags 3.2 Starting the SCSI BIOS Configuration Utility If you have SCSI BIOS Version 4.XX, and it includes the LSI Logic SCSI BIOS Configuration Utility, you can change the default configuration of your SCSI host adapters. You may decide to alter these default values if there is a conflict between device settings or if you need to optimize system performance.

  • Page 45: Configuration Utility Main Menu

    3.2.1 Configuration Utility Main Menu When you start the LSI Logic SCSI BIOS Configuration Utility, the Main Menu appears. This menu displays a list of up to four LSI Logic PCI to SCSI host adapters and information about each of them. The LSI21002 appears on the menu as two LSI53C896 entries;...

  • Page 46: Main Menu

    Figure 3.1 Main Menu Main Menu Port Irq---------Status--------NVRAM Level Current Next-Boot Found LSI53C895 FC00 LSI53C896 F800 LSI53C896 F801 Change Adapter Status Adapter Boot Order Additional Adapter Configuration Display Mode = Verbose Mono/Color Language Help Quit Below the list of host adapters on the Main Menu display, you see eight options.

  • Page 47: Change Status On Next Boot Menu

    3.2.1.2 Adapter Boot Order Adapter Boot Order allows you to set the order in which host adapters will boot when you have more than one LSI Logic host adapter in your system. When this option is selected, the Boot Order Menu appears.

  • Page 48: Utilities Menu

    3.2.1.3 Additional Adapter Configuration Additional Adapter Configuration allows you to configure an adapter that is not assigned a boot order. When this option is selected, the Adapter Configuration Menu appears. Figure 3.4 is an example of the Adapter Configuration Menu: Figure 3.4 Adapter Configuration Menu Main Menu...

  • Page 49: Utilities Menu

    3.2.1.7 Help The Help option allows the user to bring up a help screen with information about the Main Menu. 3.2.1.8 Quit The Quit option allows exiting from the SCSI BIOS Configuration Utility when the Main Menu is displayed. 3.2.1.9 Esc Pressing the Esc key allows exiting from all the screens except the Main Menu.

  • Page 50: Adapter Setup Menu

    The settings in this menu are global settings that affect the selected host adapter and all SCSI devices attached to it. SCAM Support – The LSI Logic BIOS Version 4.XX and above supports the SCSI Plug and Play protocol called SCAM. SCAM support by default is turned off in versions 4.11.00 and later for the LSI53C896...
  • Page 51 Parity – The LSI Logic PCI to SCSI host adapters always generate parity, but some older SCSI devices do not. Therefore, you are offered the option of disabling parity checking. Note: When disabling parity checking, it is also necessary to disable disconnects for all devices, as parity checking for the reselection phase is not disabled.
  • Page 52 One of these choices can be selected by highlighting it and pressing Enter. CHS Mapping – This option defines the cylinder head sector (CHS) values that will be mapped onto a disk without pre-existing partitioning information. SCSI Plug and Play Mapping is the default value. To support interchange with noncompatible systems, there is another option that can be selected by choosing CHS Mapping and then cursoring to Alternate CHS Mapping.

  • Page 53: Device Selections Menu

    This is a requirement for Microsoft Cluster Server. The default value is No with an alternate option of Yes. Termination – This option allows the user to have termination control providing an adapter has controllable termination. The default value is Auto termination.

  • Page 54: Device Selections Menu (Cont.)

    change a value, select the required device by using the arrow keys and press Enter. A new menu appears providing the options and utilities available. See an example of this menu in Figure 3.8: Figure 3.8 Device Selections Menu (Cont.) LSI53C896 Sync Rate Width...
  • Page 55 to allow other I/O processes. This option tells the host adapter whether or not to allow a device to disconnect. Some devices run faster with disconnects enabled (typically newer devices), while some run faster with disconnects disabled (typically older devices). Read/Write I/O Time-out (Seconds) –...

  • Page 56: Exiting The Scsi Bios Configuration Utility

    “Verify all sectors on the device Press ESC to abort Else press any key to continue” Help – This option displays a help screen with information about the current menu. Restore Default Setup – This option resets all device selections back to their optimal settings.

  • Page 57: Appendix A Technical Specifications

    Appendix A Technical Specifications This section discusses the physical environment associated with the LSI21002 and includes a mechanical drawing of the LSI21002 (Figure A.1). • Section A.1, “Physical Environment,” page A-1 • Section A.2, “Operational Environment,” page A-4 A.1 Physical Environment The LSI21002 has specific physical, electrical, thermal, and safety characteristics, which are described in the next sections.

  • Page 58: Physical Characteristics

    The dimensions of the LSI21002 are approximately 190.5 mm x 96.52 mm (7.5 x 3.8 inches). PCI connection is made through edge connector J1. The component height on the top and bottom of the LSI21002 follows the PCI specification. Internal 16-bit SCSI connection is made through 68-pin high density connectors;...

  • Page 59: Electrical Characteristics

    Connector J3 extends through the ISA/EISA bracket, which is attached to the face of the connector outside of the cabinet where the LSI21002 is installed. Connector J6 connects the Busy LED. It is a 4-pin, one row, right angle header and indicates bus activity for both Channel A and Channel B.

  • Page 60: Electromagnetic Compliance

    PCI bus slot, all voltages are below the SELV 42.4 V limit. A.2 Operational Environment The LSI21002 is designed for use in PCI computer systems with an ISA/EISA bracket type. The SDMS software operates the board; however, the design of the board does not prevent the use of other software.

  • Page 61: Pci Connector J1 Front Side Signals

    Table A.2 PCI Connector J1 Front Side Signals Signal Name Signal Name Signal Name −12 V +3.3 V AD27 C_BE1/ AD25 AD14 +3.3 V +5 V C_BE3/ AD12 +5 V AD23 AD10 INTB/ INTD/ AD21 KEYWAY GND (PRSNT1/) AD19 KEYWAY RESERVED +3.3 V AD08...

  • Page 62: Pci Connector J1 Back Side Signals

    Table A.3 PCI Connector J1 Back Side Signals Signal Name Signal Name Signal Name TRST/ AD28 +12 V AD26 AD15 +3.3 V AD24 AD13 +5 V IDSEL AD11 INTA/ +3.3 V INTC/ AD22 AD09 +5 V AD20 KEYWAY RESERVED KEYWAY +5 V AD18 C_BE0/...

  • Page 63: The Scsi Interface

    A.2.2 The SCSI Interface The SCSI interface conforms to ANSI X3T10.11/1142. The SCSI interface operates as two 16-bit, SE or LVD channels, and supports Fast, Ultra, and Ultra2 SCSI protocols. The interface is made through connectors J2, J3, and J4 for Channel A and J5 for Channel B. J2 is a 68-pin high density latching right angle connector for internal SCSI connections to Channel A.

  • Page 64: Scsi Connector J2, Channel A, Internal

    Table A.4 SCSI Connector J2, Channel A, Internal Signal Name Signal Name Signal Name SD7/ SDP/ CPRSNT_A TERMPWR TERMPWR SATN/ SBSY/ SD12/ SACK/ SD13/ SRST/ SD14/ SMSG/ SD15/ SSEL/ SDP1/ SC_D/ TERMPWR SD0/ SREQ/ TERMPWR SD1/ SI_O/ SD2/ SD8/ SD3/ SD9/ SD4/ SD10/...

  • Page 65: Scsi Connector J3, Channel A, External

    Table A.5 SCSI Connector J3, Channel A, External Signal Name Signal Name Signal Name CPRSNT_B TERMPWR SATN/ SD0/ SBSY/ SD1/ SACK/ SD2/ SRST/ SD3/ SSEL/ SD4/ SSEL/ SD5/ SC_D/ SD6/ SREQ/ SD7/ SI_O/ SDP/ 1. CPRSNT_B is used to sense the connection of a standard SCSI device by sensing SCSI standard GND on this pin.

  • Page 66: Scsi Connector J4, Channel A, Internal

    Table A.6 SCSI Connector J4, Channel A, Internal Signal Name Signal Name Signal Name SDP/ SD0/ SBSY/ SD1/ SACK/ CPRSNT_C SD2/ SRST/ SD3/ SMSG/ TERMPWR SD4/ SSEL/ SD5/ SC_D/ SD6/ SREQ/ SATN/ SD7/ SI_O/ 1. CPRSNT_C is used to sense the connection of a standard SCSI device by sensing SCSI standard GND on this pin.

  • Page 67: Scsi Connector J5, Channel B, Internal

    Table A.7 SCSI Connector J5, Channel B, Internal Signal Name Signal Name Signal Name SD12+ SACK+ SD7− SD13+ SRST+ SDP− SD14+ SMSG+ SD15+ SSEL+ SDP1+ SC_D+ TERMPWR SD0+ SREQ+ TERMPWR SD1+ SI_O+ SD2+ SD8+ SD3+ SD9+ SATN− SD4+ SD10+ SD5+ SD11+ SBSY−...
  • Page 68 A.2.2.1 SCSI Activity LED Interface The LSI21002 LED interface with an LED harness to be connected to the board. The connector on the LSI21002 is J6 for both channels. Table A.8 lists the signals and pin numbers for the LED connector J6.

  • Page 69: Appendix B Glossary

    A topology in which every processor is connected to two others, except for two end processors that are connected to only one other. CISPR An international committee on radio frequency interference (Committee, International and Special, for Protection in Radio). LSI21002 PCI to Dual Channel SCSI Host Adapter...
  • Page 70 Configuration Refers to the way a computer is set up; the combined hardware components (computer, monitor, key board, and peripheral devices) that make up a computer system; or the software settings that allow the hardware components to communicate with each other. Central Processing Unit.
  • Page 71 Firmware Software that is permanently stored in ROM. In the case of BIOS, it can be accessed during boot time without the aid of an operating or file system. Hard Disk A rigid disk permanently sealed into a drive cartridge. A hard disk can store very large amounts of information magnetically.
  • Page 72 Main Memory The part of a computer’s memory which is directly accessible by the CPU (usually synonymous with RAM). Mbyte Megabyte. A measure of computer storage equal to 1024 kilobytes. Motherboard See Mainboard. In some countries, the term Motherboard is not appropriate.
  • Page 73 Programmed Input/Output. A way the CPU can transfer data to and from memory using the computer’s I/O ports. PIO can be faster than DMA, but requires CPU time. Port Address Also Port Number. The address through which commands are sent to a host adapter board.
  • Page 74 (or 0–7 for an 8-bit SCSI). The host adapter is assigned ID 7 giving it priority to control the bus. SDMS Storage Device Management System. An LSI Logic software product that manages SCSI system I/O. SCSI Trade Association. A group of companies that cooperate to promote SCSI parallel interface technology as a viable mainstream I/O interconnect for commercial computing.
  • Page 75 Wide SCSI A SCSI-2 feature allowing 16 or 32-bit transfers on the SCSI bus. This dramatically increases the transfer rate over the standard 8-bit SCSI bus. Wide Ultra SCSI The STA term for SCSI bus width 16 bits, SCSI bus speed maximum data rate 40 Mbytes/s.
  • Page 76 Glossary...
  • Page 77 I/O time-out 3-14 restore default setup 3-13 scan for device at boot time main menu display 3-13 scan for SCSI logical units main menu options 3-12 sync rate display mode LSI21002 PCI to Dual Channel SCSI Host Adapter IX-1...
  • Page 78 main menu options (Cont.) esc key help 3-13 verify option language volts mono/color 3.3 V/5 V bus support quit 3-12 width option parity PCI interface PCI Slot 2-22 peripheral devices preset host adapter setting 2-22 SCSI ID 7 3-13 queue tags quit option 3-13 read/write I/O time-out (seconds)

  • Page 79: Customer Feedback

    Please include your name, phone number, fax number, and company address so that we may contact you directly for clarification or additional information. Thank you for your help in improving the quality of our documents. LSI21002 PCI to Dual Channel SCSI Host Adapter...
  • Page 80 LSI Logic Corporation Technical Publications M/S E-198 Fax: 408.433.4333 Please tell us how you rate this document: LSI21002 PCI to Dual Channel SCSI Host Adapter User’s Guide. Place a check mark in the appropriate blank for each category. Excellent Good Average...
  • Page 81 U.S. Distributors by State A. E. Avnet Electronics Colorado Illinois Michigan http://www.hh.avnet.com Denver North/South Brighton B. M. Bell Microproducts, A. E. Tel: 303.790.1662 A. E. Tel: 847.797.7300 I. E. Tel: 810.229.7710 Inc. (for HAB’s) B. M. Tel: 303.846.3065 Tel: 314.291.5350 Detroit http://www.bellmicro.com W.
  • Page 82 U.S. Distributors by State (Continued) New York South Carolina Washington Hauppauge A. E. Tel: 919.872.0712 Kirkland I. E. Tel: 516.761.0960 W. E. Tel: 919.469.1502 I. E. Tel: 425.820.8100 Long Island Maple Valley South Dakota A. E. Tel: 516.434.7400 B. M. Tel: 206.223.0080 A.
  • Page 83 Direct Sales Representatives by State (Components and Boards) E. A. Earle Associates Texas E. L. Electrodyne - UT Austin Group 2000 Tel: 512.794.9006 I. S. Infinity Sales, Inc. Arlington ION Associates, Inc. Tel: 817.695.8000 R. A. Rathsburg Associ- Houston ates, Inc. Tel: 281.376.2000 Synergy Associates, Utah...
  • Page 84 Sales Offices and Design Resource Centers LSI Logic Corporation Fort Collins New Jersey Canada Corporate Headquarters 2001 Danfield Court Red Bank Ontario Fort Collins, CO 80525 1551 McCarthy Blvd 125 Half Mile Road Ottawa Tel: 970.223.5100 Milpitas CA 95035 Suite 200 260 Hearst Way Tel: 408.433.8000...
  • Page 85 Sales Offices and Design Resource Centers (Continued) Korea Seoul LSI Logic Corporation of Korea Ltd 10th Fl., Haesung 1 Bldg. 942, Daechi-dong, Kangnam-ku, Seoul, 135-283 Tel: 82.2.528.3400 Fax: 82.2.528.2250 The Netherlands Eindhoven LSI Logic Europe Ltd World Trade Center Eindhoven Building ‘Rijder’...
  • Page 86 Switzerland Tel: 44.1793.849933 Bangalore, India 560078 Xicheng District ♦ Brugg Fax: 44.1793.859555 Tel: 91.80.664.5530 Beijing 100045, China LSI Logic Sulzer AG Tel: 86.10.6804.2534 to 38 Fax: 91.80.664.9748 Mattenstrasse 6a Fax: 86.10.6804.2521 ♦ CH 2555 Brugg Sales Offices with Israel Tel: 41.32.3743232...
