Page 1: Host Bus Adapter
LSI® SAS 9207-8e PCI Express® to 6Gb/s Serial Attached SCSI (SAS) Host Bus Adapter User Guide Version 2.2 August 2012 DB15-000859-03... -
Page 2: Revision History
LSI Corporation reserves the right to make changes to the product(s) or information disclosed herein at any time without notice. LSI Corporation does not assume any responsibility or liability arising out of the application or use of any product or service described herein, except as expressly agreed to in writing by LSI Corporation; nor does the purchase, lease, or use of a product or service from LSI Corporation convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Corporation or of third parties. -
Page 3: Table Of Contents
LSI SAS 9207-8e PCI Express to 6Gb/s SAS HBA User Guide Table of Contents August 2012 Table of Contents LSI SAS 9207-8e PCI Express to 6Gb/s SAS HBA User Guide ............... . 4 1 Overview . -
Page 4: Lsi Sas 9207-8E Pci Express To 6Gb/S Sas Hba User Guide
The low-profile design of the SAS HBA includes a full-height bracket and low-profile mounting bracket that creates a universal fit for any server. The LSI SAS 9207-8e HBA is based on the Fusion-MPT™ architected LSI SAS 2308 controller that integrates the latest enhancements in PCIe 3.0 technology and 6Gb/s SAS technology. -
Page 5: Sas-2 Interface
LSI SAS 9207-8e HBA Characteristics Flash The LSI SAS 9207-8e HBA has onboard Flash ROM for the firmware and BIOS. The LSI SAS 9207-8e HBA provides one 4 M x 16-bit Flash ROM for storing the firmware and the BIOS. -
Page 6: Physical Characteristics
Physical Characteristics The LSI SAS 9207-8e HBA is a 6.6-in. x 2.7-in., low-profile board. The component height on the top and bottom of the LSI SAS 9207-8e HBA is in accordance with the PCIe specification. The following figure shows the board layout. -
Page 7: Lsi Sas 9207-8E Hba Certifications And Safety Characteristics
LSI SAS 9207-8e HBA Certifications and Safety Characteristics The LSI SAS 9207-8e HBA meets or exceeds the requirements of UL flammability rating 94V-0. Each bare board is marked with the supplier’s name or trademark, type, and UL flammability rating. Because these boards are installed in a PCIe bus slot, all voltages are less than the SELV 42.4-V limit. -
Page 8: Technical Support
HBA connectors. The LSI SAS 9207-8e HBA has two external x4 mini-SAS connectors. For external connections, use a cable with an external mini-SAS connector (SFF-8088) on one end (to connect to the HBA) and the appropriate connector to attach to the SAS or SATA devices on the other end.
