LSI LSI22910 User Manual

Pci to dual channel ultra2 scsi host adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S
GUIDE
LSI22910
PCI to Dual Channel
Ultra2 SCSI
Host Adapter
Version 1.1
D e c e m b e r 2 0 0 0
®
S14018.A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSI22910 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LSI LSI22910

Summary of Contents for LSI LSI22910

  • Page 1 USER’S GUIDE LSI22910 PCI to Dual Channel Ultra2 SCSI Host Adapter Version 1.1 D e c e m b e r 2 0 0 0 ® S14018.A...
  • Page 2 Consult the dealer or an experienced radio/TV technician for help. Shielded cables for SCSI connection external to the cabinet are used in the compliance testing of this Product. LSI Logic is not responsible for any radio or television interference caused by unauthorized modification of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by LSI Logic.
  • Page 3 LSI Logic; nor does the purchase or use of a product from LSI Logic convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Logic or third parties.
  • Page 5 Preface This book is the primary reference and user’s guide for the LSI Logic LSI22910 PCI to Dual Channel Ultra2 SCSI Host Adapter. It contains a complete functional description for the LSI22910 and includes complete physical and electrical specifications for the LSI22910.
  • Page 6 Related Publications PCI Storage Device Management System SDMS™ 4.0 User’s Guide, Order Number S14007.A Revision Record Revision Date Remarks 5/99 Final version. 12/00 All product names changed from SYM to LSI. Preface...

  • Page 7: Table Of Contents

    Contents Chapter 1 Using the LSI22910 General Description Features 1.2.1 PCI Interface 1.2.2 SCSI Interface 1.2.3 Board Characteristics Interface Descriptions 1.3.1 The PCI Interface 1.3.2 The SCSI Interface 1.3.3 SCSI Activity LED Interface 1.3.4 Wide Ultra2 SCSI Chapter 2 Installing the LSI22910...
  • Page 8 Chapter 3 Configuring the LSI22910 When to Configure the LSI22910 Starting the SCSI BIOS Configuration Utility 3.2.1 Configuration Utility Main Menu 3.2.2 Utilities Menu 3.2.3 Device Selections Menu 3-11 Exiting the SCSI BIOS Configuration Utility 3-14 Appendix A Technical Specifications Physical Environment A.1.1...
  • Page 9 Change Status on Next Boot Menu Boot Order Menu Adapter Configuration Menu Utilities Menu Adapter Setup Menu Device Selections Menu 3-11 Device Selections Menu (Cont.) 3-12 LSI22910 Mechanical Drawing Tables Standard Cables SCSI ID Record 2-22 Setting Interrupts 2-23 Global Default Settings Device Default Settings...
  • Page 10 Contents...

  • Page 11: Chapter 1 Using The Lsi22910

    Chapter 1 Using the LSI22910 This chapter describes the LSI22910 PCI to Dual Channel Ultra2 SCSI Host Adapter interface to PCI computer systems and includes these topics: • Section 1.1, “General Description,” page 1-1 • Section 1.2, “Features,” page 1-2 •...

  • Page 12: Features

    1.2 Features This section provides a high level overview of the PCI Interface, the SCSI Interface, and Board Characteristics for the LSI22910. 1.2.1 PCI Interface The PCI interface includes these features: • Full 32-bit or 64-bit (33 MHz) DMA bus master •...

  • Page 13: Board Characteristics

    PCI is a high-speed standard local bus for interfacing a number of I/O components to the processor and memory subsystem in a high end PC. The PCI functionality for the LSI22910 is contained within the LSI Logic LSI53C896 PCI to SCSI I/O Processor chip. The LSI53C896 connects directly to the PCI bus and generates timing protocol in compliance with the PCI Local Bus Specification Revision 2.1 standard.

  • Page 14: Scsi Activity Led Interface

    1.5 A short circuit protection device. An on-board LED lights up when TERMPWR is shorted and turns off. A 40 MHz oscillator is installed on the LSI22910 board to provide the clock frequency to the LSI53C896 that is necessary to support Wide Ultra2 SCSI transfers of up to 80 Mbytes/s.

  • Page 15: Wide Ultra2 Scsi

    SCSI bus connections. When you purchased the LSI22910 kit, the cable provided in the kit is matched for a Fast/Ultra/Ultra2 SE or LVD operation. This cable also has built-in LVD termination since most Ultra2 hard disk drives are not made with on-board LVD termination.
  • Page 16 Using the LSI22910...

  • Page 17: Chapter 2 Installing The Lsi22910

    Step 1. Ground yourself before removing this host adapter board. Remove the LSI22910 from the packing and check that it is not damaged. An example of this host adapter board is shown in Figure 2.1...
  • Page 18 64-bit slot. Refer to the user’s manual supplied with your computer to confirm the location of the PCI slots. The LSI22910 requires a PCI slot that allows bus master operation. See Figure 2.2.

  • Page 19: Detailed Installation Procedure

    2.2 Detailed Installation Procedure This section provides step-by-step instructions for installing the LSI22910, and connecting it to your SCSI peripherals. If you are experienced in these tasks, you may prefer to use the preceding Section 2.1, “Quick Installation Procedure.” If you are not confident that you can perform the tasks as described here, LSI Logic suggests getting assistance.

  • Page 20: Inserting The Host Adapter

    Step 1. Ground yourself before removing this host adapter board. Remove the LSI22910 from the packing and check that it is not damaged. An example of this host adapter board is shown in Figure 2.1.

  • Page 21: Hardware Connections For The Lsi22910

    Figure 2.1 Hardware Connections for the LSI22910 Channel A Channels A & B 68-pin Internal Busy LED High Density Connector SCSI Interface Channel B 68-pin Internal High Density SCSI Interface Channel B 68-pin External High Density SCSI Interface Channel A...

  • Page 22: Inserting The Host Adapter

    Step 7. The bracket around the connectors J2 and J3 (see Figure 2.1) should fit where you removed the blank panel. Secure it with the bracket screw (see Figure 2.2) before making the internal and external SCSI bus connections. Installing the LSI22910...

  • Page 23: Connecting The Scsi Peripherals

    2.2.3 Connecting the SCSI Peripherals All internal SCSI bus connections to the LSI22910 are made with an unshielded, 68-conductor ribbon cable (see Figure 2.3). One side of this cable is marked with a color to indicate the pin-1 side. The connectors on this cable are keyed to ensure proper pin-1 connection.

  • Page 24: Making Internal Scsi Bus Connections

    Step 1. To connect an internal SCSI device, plug the 68-pin connector on one end of a wide internal SCSI ribbon cable into the connector J4 or J5. See the example in Figure 2.4. Figure 2.4 Internal SCSI Ribbon Cable to Host Adapter Installing the LSI22910...

  • Page 25: Internal Scsi Ribbon Cable To Internal Scsi Device

    Step 2. Plug the 68-pin connector on the other end of the internal SCSI ribbon cable into the SCSI connector on the internal SCSI device. Pin 1 must match on all connections. An example of this connection appears in Figure 2.5.
  • Page 26 See the example in Figure 2.6. An example of multiple internal SCSI devices chained together is shown in Figure 2.7. Make sure to match pin 1 on all connections. Figure 2.6 Connecting Additional Internal SCSI Devices 2-10 Installing the LSI22910...
  • Page 27 Figure 2.7 Multiple Internal SCSI Devices Chained Together Detailed Installation Procedure 2-11...
  • Page 28 Figure 2.8. This connection causes the front panel LED to indicate activity on the SCSI bus. An LED is also on the LSI22910, which indicates activity on the SCSI bus. The Busy LED connector J6, as shown in Figure 2.1, is not keyed.

  • Page 29: Making External Scsi Bus Connections

    This section provides step-by-step instructions about making external SCSI bus connections. Step 1. If you need to connect external SCSI devices to the LSI22910, plug the 68-pin VHDCI connector on one end of a shielded external high density cable (see Figure 2.3) into the host...

  • Page 30: External Cable To External Scsi Device

    Step 2. Plug the 68-pin connector on the other end of the shielded external SCSI cable into the SCSI connector on your external SCSI device. An example of this connection is shown in Figure 2.10. Figure 2.10 External Cable to External SCSI Device 2-14 Installing the LSI22910...
  • Page 31 Step 3. If you need to connect more than one external SCSI device to your host adapter, chain them together with shielded external SCSI cables. See the example in Figure 2.11. Figure 2.11 Multiple External SCSI Devices Chained Together Detailed Installation Procedure 2-15...

  • Page 32: Scsi Bus Termination

    SCSI bus must have their terminators active. All other SCSI devices on the bus must have their terminators removed or disabled. Remember that your LSI22910 is also on the SCSI bus—its termination is automatically enabled when it is connected to the end of the bus.
  • Page 33 Only for internal SCSI connections, • Only for external SCSI connections, and • Connections to both internal and external SCSI connections. Termination on the LSI22910 for these three different bus configurations are discussed below. Autotermination enabled Termination disabled Detailed Installation Procedure...

  • Page 34: Internal Scsi Connections

    Termination on your host adapter is automatically enabled in this case. Figure 2.12 shows an example of how termination is determined for this SCSI bus configuration. Figure 2.12 Internal SCSI Device Termination 2-18 Installing the LSI22910...

  • Page 35: External Scsi Connections

    2.2.8 External SCSI Connections If you have only external SCSI device connections on your host adapter, you must terminate the last external device on the SCSI bus. You must disable the termination on all other devices. Termination on your host adapter is automatically enabled in this case.

  • Page 36: Internal And External Scsi Connections

    SCSI bus configuration on your host adapter Channel B. Figure 2.14 Internal and External SCSI Device Termination Last Device on Chain – Termination Enabled Host Adapter Does Not Termination End Chain Automatically Termination Disabled Disabled Last Device on Chain Termination Enabled 2-20 Installing the LSI22910...

  • Page 37: Setting Scsi Ids

    Note: If an internal connection to another LSI22910 has been made, or any connection to a device that uses the same sensing method for automatic termination as your LSI22910, override the termination for that channel by adding a shunt or through software control.

  • Page 38: Scsi Id Record

    Table 2.1 SCSI ID Record SCSI ID SCSI Device Channel A SCSI Device Channel B LSI22910 (default) LSI22910 (default) 2-22 Installing the LSI22910...

  • Page 39: Setting Interrupts

    2.2.11 Setting Interrupts Normally, you do not change the default interrupt routing for the LSI22910, since performance is usually increased by having two separate interrupts. However, if your system does not support two separate interrupts, INTA/INTB (see Figure A.1) is provided to change the interrupt routing.

  • Page 40: Completing The Installation

    Step 3. Wait for your computer to boot up. Step 4. To change the configuration of your host adapter, see Chapter 3, “Configuring the LSI22910.” Finally, refer to the PCI Storage Device Management System SDMS 4.0 User’s Guide (or the guide for the software you will use) to load the driver software for your particular operating system.

  • Page 41: Chapter 3 Configuring The Lsi22910

    Chapter 3 Configuring the LSI22910 This chapter describes configuring the LSI22910 and includes these topics: • Section 3.1, “When to Configure the LSI22910,” page 3-1 • Section 3.2, “Starting the SCSI BIOS Configuration Utility,” page 3-2 • Section 3.3, “Exiting the SCSI BIOS Configuration Utility,” page 3-14 3.1 When to Configure the LSI22910...

  • Page 42: Starting The Scsi Bios Configuration Utility

    1. Logical Unit Number. 3.2 Starting the SCSI BIOS Configuration Utility If you have LSI Logic SCSI BIOS Version 4.0, and it includes the LSI Logic SCSI BIOS Configuration Utility, you can change the default configuration of the SCSI host adapters. You may decide to alter these default values if there is a conflict between device settings or if you need to optimize system performance.

  • Page 43: Configuration Utility Main Menu

    3.2.1 Configuration Utility Main Menu When you start the LSI Logic SCSI BIOS Configuration Utility, the Main Menu appears. This menu displays a list of up to four LSI Logic PCI to SCSI Host Adapters and information about each of them. The LSI22910 appears on the menu as two LSI53C896 entries;...

  • Page 44: Main Menu

    SCSI devices attached to it. When this option is used to make a change, the change takes place after a reboot upon exit from the utility. Figure 3.2 is an example of the Change Status on Next Boot menu. Configuring the LSI22910...

  • Page 45: Change Status On Next Boot Menu

    3.2.1.2 Adapter Boot Order Adapter Boot Order allows the user to set the order in which host adapters will boot when you have more than one LSI Logic host adapter in your system. When this option is selected, the Boot Order menu appears.

  • Page 46: Adapter Configuration Menu

    3.2.1.6 Language If enabled, the Language option allows the user to select from five languages for the Configuration Utility: English, German, French, Italian, and Spanish. Call for support if you have any additional questions. Configuring the LSI22910...

  • Page 47: Utilities Menu

    3.2.1.7 Help The Help option displays a help screen with information about the Main Menu. 3.2.1.8 Quit The Quit option allows exiting from the SCSI BIOS Configuration Utility when the Main Menu is displayed. 3.2.1.9 Esc Pressing the Esc key allows exit from all the screens except the Main Menu.

  • Page 48: Adapter Setup Menu

    The settings in this menu are global settings that affect the selected host adapter and all SCSI devices attached to it. SCAM Support – The LSI Logic BIOS Version 4.0 and above supports the SCSI Plug and Play protocol called SCAM. SCAM support by default is off in versions 4.11.00 and later for the LSI53C896.
  • Page 49 Note: When disabling parity checking, it is also necessary to disable disconnects for all devices, as parity checking for the reselection phase is not disabled. If a device does not generate parity, and it disconnects, the I/O never completes because the reselection never completes. Host SCSI ID –...
  • Page 50 Format utility or the FDISK/MBR command that you target the correct disk. After clearing the partitions and data, it is necessary to reboot and clear memory or the old partitioning data will be reused, thus nullifying the previous operation. 3-10 Configuring the LSI22910...

  • Page 51: Device Selections Menu

    3.2.3 Device Selections Menu When you select the Device Selections option, the menu shown in Figure 3.7 appears. Figure 3.7 Device Selections Menu LSI53C896 Device Selections 0-7 Sync Data Disc Time Scan Queue Rate Width LUNS Tags 0-Dev0 N/A Enabled 1-Dev1 N/A Enabled 2-Dev2 N/A...

  • Page 52: Device Selections Menu (Cont.)

    I/O processes. Additionally, it tells the host adapter whether or not to allow a device to disconnect. Some devices run faster with disconnects enabled (typically newer devices), while some run faster with disconnects disabled (typically older devices). 3-12 Configuring the LSI22910...
  • Page 53 Read/Write I/O Time-out (seconds) – This option sets the amount of time the host adapter waits for a read, write, or seek command to complete before trying the I/O transfer again. Since this provides a safeguard allowing the system to recover if an I/O operation fails, it is recommended that you always set the time-out to a value greater than zero.

  • Page 54: Exiting The Scsi Bios Configuration Utility

    Configuration Utility properly. Return to the Main Menu and exit by using the Quit option. Important: Rebooting the system without properly exiting from this utility may cause some changes to not take effect. 3-14 Configuring the LSI22910...

  • Page 55: Appendix A Technical Specifications

    The dimensions of the LSI22910 are approximately 9.5 x 4.0 inches. PCI connection is made through edge connector J1. The component height on the top and bottom of the LSI22910 follows the PCI Local Bus Specification Revision 2.1 standard. Internal 16-bit SCSI connection is made through the 68-pin high density connector J5 (or J4 for Channel B).

  • Page 56: Electrical Characteristics

    A _ TERM LSI53C896 B _ TERM Channel A INTA/INTB A.1.2 Electrical Characteristics The LSI22910 maximum power requirements, which include SCSI TERMPWR, under normal operation are as follows: Table A.1 Maximum Power Requirements Over the operating range 5–55 ° C ±...

  • Page 57: Thermal, Atmospheric Characteristics

    A.1.3 Thermal, Atmospheric Characteristics The board is designed to operate in an environment, which is defined by the following parameters: • Temperature range: 5 ° C to 55 ° C (dry bulb) • Relative humidity range: 5% to 90% noncondensing •...

  • Page 58: Operational Environment

    A.2 Operational Environment The LSI22910 is designed for use in PCI computer systems with an ISA/EISA bracket type. The SDMS software operates the board, but the design of the board does not prevent the use of other software. A.2.1 The PCI Interface The PCI interface operates as a 32-bit or 64-bit DMA bus master.

  • Page 59: Pci Connector J1 (Front

    Table A.2 PCI Connector J1 (Front) Signal Name Signal Name Signal Name − 12 V C_BE2 RESERVED IRDY C_BE6 +3.3 V C_BE4 +5 V DEVSEL +5 V AD63 INTB LOCK AD61 INTD PERR 3 V/5 V GND(PRSNT1 +3.3 V AD59 RESERVED SERR AD57...

  • Page 60: Pci Connector J1 (Back

    Table A.3 PCI Connector J1 (Back) Signal Name Signal Name Signal Name TRST +3.3 V +12 V FRAME C_BE7 C_BE5 TRDY 3 V/5 V +5 V PAR64 INTA STOP AD62 INTC +3.3 V +5 V SDONE AD60 RESERVED AD58 3 V/5 V RESERVED AD56 KEYWAY...

  • Page 61: The Scsi Interface

    A.2.2 The SCSI Interface The SCSI interface operates as two 16-bit, synchronous or asynchronous, SE or LVD bus, and supports Ultra2 SCSI protocols and 16-bit arbitration. The interface is made through connectors J2 and J5 for Channel A and J4 and J3 for Channel B. Connectors J2 and J3 are 68-pin VHDCI right-angle receptacles that protrude through the ISA/EISA bracket.
  • Page 62 Table A.4 SCSI Interface Signal Name Signal Name Signal Name SD7 − SD12+ SACK+ SDP − SD13+ SRST+ SD14+ SMSG+ SD15+ SSEL+ CPRSNT SDP1+ SC_D+ TERMPWR SD0+ SREQ+ TERMPWR SD1+ SI_O+ SD2+ SD8+ SATN − SD3+ SD9+ SD4+ SD10+ SBSY − SD5+ SD11+ SD12 −...
  • Page 63 SCSI Activity LED Interface – The LSI22910 LED interface is a four-wire arrangement that allows you to connect an LED harness to the board. The connector on the LSI22910 is J6 for both channels. Table A.5 lists the signal and pin numbers for the LED interface for this SCSI host adapter.
  • Page 64 A-10 Technical Specifications...

  • Page 65: Appendix B Glossary Of Terms And Abbreviations

    A topology in which every processor is connected to two others, except for two end processors that are connected to only one other. CISPR A special international committee on radio interference (Committee, International and Special, for Protection in Radio). LSI22910 PCI to Dual Channel Ultra2 SCSI Host Adapter...
