Standard Installation - Dynojet POWER COMMANDER III Installation Instructions

There are two methods of installation of the Power Commander.
1 The Standard install takes 30 minutes to accomplish, but the fit is better.
2 The Quick install takes about 15 minutes. While this method is easier,
it may allow wiring to be visible with certain aftermarket seat assemblies.
i802-511 www.powercommander.com

STANDARD INSTALLATION

Loosen these bolts
PCIII connector
1 Remove the seat.
2 Remove saddlebags if installed.
3 Remove left and right side
covers.
4 Remove the battery (negative
terminal first)
5 Loosen the two 7/16 nuts that
retain the ECM to the battery
tray enough to pull the ECM
away from the frame (Fig. A).
6 From the left side (underneath
the left side cover area) feed the
PC III connectors in front of bat-
tery tray, and out the right side
(in front of the ECU bracket)
(Fig. B).
99-01 Harley Davidson TC88 - PCIII USB - 2
.
