Introduction
Purpose
This field service bulletin describes the steps necessary to replace the capacitors in the Powermax45.
Powermax45 XP systems: Complete instructions for installing this kit are included in the Powermax45 XP Service
Manual (809230). To download the manual, go to www.hypertherm.com/docs.

Tools and materials needed

 Assorted Phillips and TORX
®
 Needlenose pliers
228301 Kit contents (200–240 V CSA and 230 V CE)
Part number
075697
109659
228426 Kit contents (400 V CE)
Part number
075697
109673
428080 Kit contents (480 V CSA)
Part number
075697
209197
Powermax45/45 XP Field Service Bulletin 805950
Disconnect electrical power before performing any maintenance. See the
Safety and Compliance Manual (80669C) for more safety precautions.
screwdrivers
®
Description
Machine screw: M5 x 0.8 x 10
Capacitor: 5600UF 250VDC
Description
Machine screw: M5 x 0.8 x 10
Capacitor: 2200UF 400VDC
Description
Machine screw: M5 x 0.8 x 10
Capacitor: 1800UF 450VDC
Powermax45/45 XP Capacitor Replacement Kit
DANGER!

ELECTRIC SHOCK CAN KILL

Quantity
4
2
Quantity
4
2
Quantity
4
2
1
