Troubleshooting

Indication
Red solid light
Red flashing light Malfunctioning connector
Yellow solid light
Yellow flashing light Engine lock socket is not in the locked
No indication
If the prescribed actions do not help, contact a qualified electrician.

Technical data

Specifikations
Standards/directives:
Assembly:
Rated voltage:
Installation system:
Charging type:
Enclosure class:
Mechanical impact resistance: IK08
Operating temperature:
Assembly height
Weight:
380130 EDITION 2
Type of error
Residual current device or residual
current circuit breaker with over cur-
rent protection has tripped
Inappropriate cable
position
IEC 61851-1, 61851-22 och IEC TS 61439-7
Only wall mounting
230V/400V 50Hz
TT, TN and IT system. (S-marked for TT & TN system)
Mode 3
IP44
-25˚C - +40 ˚C
0.5-1.5 metres floor/ground to the lower edge of the charger
Approximately 3 kg with socket
3,8-4,1 kg with cable and connectors, 1-phase
5,4 kg with cable and connectors, 3-phase
Action
Reset, see section: Resetting the residual cur-
rent device or residual current circuit breaker
with over current protection
Contact a qualified electrician
Check that the correct type of cable is used. A
16A cable cannot be used in a 32A charger
Contact a qualified electrician
Check the feeding fuse
