Fault Isolation And Recovery - Transition Networks CFETF10 Series User Manual

CFETF10xx-205

FAULT ISOLATION AND RECOVERY

If the Media Converter fails, isolate and correct the failure by determining the
answers to the following questions and then taking the indicated action:
1. Is the PWR LED on the Media Converter illuminated?
NO
• Is the Media Converter Slide-in-Module installed properly in the
chassis?
• Is the power cord properly installed in the chassis and at the external
power source?
• Does the external power source provide power?
• Contact Technical Support: 1-800-260-1312 (Int'l: 00-1-952-7600).
YES
• Proceed to step 2.
2. Is the LKC LED on the Media Converter illuminated?
NO
• Check the twisted-pair cables for proper connection.
• Contact Technical Support: 1-800-260-1312 (Int'l: 00-1-952-7600).
YES
• Proceed to step 3.
3. Is the LKF LED on the Media Converter illuminated?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables on the Media Converter are
connected to the RX and TX ports, respectively, on the other device.
• Contact Technical Support: 1-800-260-1312 (Int'l: 00-1-952-7600).
YES
• Proceed to step 4.
4. Is the RXC LED on the Media Converter flashing?
NO
• If there is no activity on the 100Base-TX port, proceed to step 5.
• If there is activity on the 100Base-TX port, disconnect and reconnect
the 100Base-TX cable to restart the initialization process.
• Restart the workstation to restart the initialization process.
• Contact Technical Support: 1-800-260-1312 (Int'l: 00-1-952-7600).
YES
• Proceed to step 5.
5. Is the RXF LED on the Media Converter flashing?
NO
• If there is no activity on the 100Base-FX port, continue below
• If there is activity on the 100Base-FX port, disconnect and reconnect
the 100Base-FX cable to restart the initialization process.
• Verify that the TX and RX cables on the Media Converter are
connected to the RX and TX ports, respectively, on the other device.
• Restart the workstation to restart the initialization process.
• Contact Technical Support: 1-800-260-1312 (Int'l: 00-1-952-7600).
YES
• Contact Technical Support: 1-800-260-1312 (Int'l: 00-1-952-7600).
