Working with the VDO SmartTerminal

Working with the VDO SmartTerminal
The display of the VDO SmartTerminal is split into three areas. At the top, you
always find the current position in the navigation of the device. At the bottom,
the terminal shows the current time and date and through the symbol on the
right enables switching to the settings. The work area is located in the middle.
The operation of the device is done via the display.

Initial installation

Before you can use the VDO SmartTerminal, you must transfer an encryption
onto the device. This is necessary for data protection reasons as it is a portable
device.
You can perform the initial installation of the device via the VDO TerminalTools.
Afterwards, you can download data onto the device.

Settings

Some of the settings which are made via VDO TerminalTools can also be
made directly on the device. However, for most of the settings the operator
needs to enter an administration PIN in order to be able to make changes. This
can be set in the VDO TerminalTools per device.
Click on the gearwheel in the bottom right to access the settings at any time.

Information

The area Information contains all important information which you require, e.g.
for initial installation.
The following information is displayed:
Information Description
Version Displays the current firmware version, including update
level
