Selecting Programmable Switch Functions

The programmable switch on the top panel can be configured using the menu
to provide several functions:
Power - turns the power on and off
•
• Mute - mutes the audio when switched on
TalkBk (talkback) - redirects the audio to a different output channel on
•
the receiver (with receivers that offer this function)
(none) - disables the switch
•
Gain
Freq.
ProgSw
Compat
ProgSw
TalkBk
NOTE: The programmable switch will continue to operate whether or
not keypad changes are locked.
IR (infrared) Sync
The opening on the side panel is an IR port for quick setup using a receiver
with this capability. The transfer is initiated with a switch on the receiver.
IR Port
The receiver can transfer the settings for Frequency, Step Size and Compat-
ibility mode to the transmitter via the IR ports. When the settings are success-
fully transferred, OK will appear on the transmitter LCD. If a mismatch exists,
an error message will appear on the transmitter LCD indicating the nature of
the problem.
IR Sync
OK
www.lectrosonics.com
ProgSw
Power
ProgSw
(none)
FCCID:DBZLMBC1
Lectrosonics, Inc.
Made in U.S.A.
IR Sync
BLOCK
Mismatch
ProgSw
Mute
Use the and
arrow buttons to
select the desired
function or disable
the switch
614.4 - 691.1 MHz
S/N XXXXX
Model: LMBC1
IC: 8024A-LMBC1
IR Sync
COMPAT
Mismatch
11
