Locking/Unlocking Changes to Settings

Changes to the settings can be locked.
StepSize Locked?
Phase
Locked
Backlit
A small padlock symbol will appear on adjustment
screens when changes have been locked.
When changes are locked, several controls and actions
can still be used:
menu or removing the batteries.

Selecting Programmable Switch Functions

The programmable switch on the top panel can be con-
figured using the menu to provide several functions:
Power - turns the power on and off
Mute - mutes the audio when switched on
TalkBk (talkback) - redirects the audio to a different
output channel on the receiver (with receivers that
offer this function)
(none) - disables the switch
ProgSw
Gain
Freq.
ProgSw
Compat
ProgSw ProgSw
TalkBk
NOTE: The programmable switch will continue
to operate whether or not keypad changes are
locked.
Rio Rancho, NM
Gain
No
Yes
-40
-20
ProgSw
Power Mute
Use the
arrow buttons to
select the desired
Mute
function or disable
the switch
Digital Hybrid Wireless Belt-Pack Transmitter

Main Window Indicators

The Main Window displays the block number, Standby
or Operating mode, operating frequency, audio level,
battery status and programmable switch function. When
the frequency step size is set at 100 kHz, the LCD will
25
look like the following.
Block number
0
Frequency
(hex setting)
Frequency (MHz)
When the frequency step size is set to 25 kHz, the hex
number may include a fraction.
1/4 = .025 MHz
1/2 = .050 MHz
3/4 = .075 MHz
Changing the step size never changes the frequency.
It only changes the way the user interface works. If the
frequency is set to a fractional increment between even
100 kHz steps and the step size is changed to 100 kHz,
the hex code will be replaced by two asterisks on the
main screen and the frequency screen.
Frequency set to fractional 25 kHz step,
but step size changed to 100 kHz.
b 19
MUTE
494.525
-40 -20
and
If the programmable switch function is set for Mute, the
Main Window will indicate that the function is enabled.
b 19
51
MUTE
494.500
-40 -20
When the switch is turned on, the mute icon appear-
ance will change, the word MUTE will blink at the bot-
tom of the display, and the power/function LED will blink
blue.
Operating mode
b 19
Battery status
5 1
MUTE
494.500
Programmable
switch function
-40 -20 0
Audio level
Fraction
b 19
1
51
MUTE
4
494.525
kHz from the upper
-40 -20
0
Freq.
b 19
494.525
0
Mute function
enabled but
not active
0
Note that the
frequency has
increased by 25
example.
9
