Lectrosonics SMDB/E01 Series Instruction Manual
Super miniature transmitters with digital hybrid wireless technology
Hide thumbs
Also See for SMDB/E01 Series:
- Quick start manual (12 pages) ,
- Instruction manual (24 pages)
Table of Contents
Advertisement
SMB/E01Series
Super Miniature Transmitters
With Digital Hybrid Wireless
US Patent 7,225,135
SMDB/E01
Dual battery
SMB/E01
Single battery
RM/E
Remote Control
SMBATELIM
Battery eliminator
Fill in for your records:
Serial Number:
Purchase Date:
Technology
®
INSTRUCTION MANUAL
Rio Rancho, NM, USA
www.lectrosonics.com
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Lectrosonics SMDB/E01 Series
Summary of Contents for Lectrosonics SMDB/E01 Series
- Page 1 INSTRUCTION MANUAL SMB/E01Series Super Miniature Transmitters With Digital Hybrid Wireless Technology ® US Patent 7,225,135 SMDB/E01 Dual battery SMB/E01 Single battery RM/E Remote Control SMBATELIM Battery eliminator Fill in for your records: Serial Number: Purchase Date: Rio Rancho, NM, USA www.lectrosonics.com...
-
Page 2: Table Of Contents
Setting Transmitter Operating Frequency ............................9 5-Pin Input Jack Wiring ................................. 10 Installing the Connector: ................................10 Microphone Cable Termination for Non-Lectrosonics Microphones ..................11 Microphone RF Bypassing ................................12 Line Level Signals ..................................12 Wiring Hookups for Different Sources ............................13 Compatible Wiring for Both Servo Bias Inputs and Earlier Transmitters: .................. -
Page 3: Introduction
Super-Minature Belt Pack Transmitters Introduction The SMB Series transmitters are the product of many years of engineering and experience in professional audio markets. The unique design provides several distinct features for professional applications: • Superb, compandor-free audio quality • Ultra-lightweight, corrosion resistant housing •... -
Page 4: General Technical Description
FM ers slowly from sustained high levels to keep audio wireless systems and it does away with the analog distortion low while preserving short term dynamics. compandor and its artifacts. Regulator Variable 1.8 - 4v LECTROSONICS, INC. -
Page 5: Signal Encoding And Pilot Tone
25.6 yields the block number. For example, flexibility of digital signal processing, they can also 640.000 divided by 25.6 equals 25. In other words, operate with Lectrosonics Euro version IFB receivers. block 25 starts at 640.000 MHz. Control Panel... -
Page 6: Controls And Functions
MHz and a two-digit maining time. hexadecimal number that corresponds to the equiva- Varies lent Lectrosonics Frequency Switch Setting. Green Blink The FREQ button is also used with the AUDIO button to enter standby mode and to turn the transmitter on or off. -
Page 7: Setup Screens
Several “Dweedle tones” can also be downloaded displays. Press and hold the FREQ button and use from the web site at: the Up and Down arrows to select the frequency. http://www.lectrosonics.com/europe/en/Transmitters/ Lock/Unlock Screen rm.html Simultaneously pressing The dweedle tones can be played back through an and holding both the Up MP3 player, PDA, smart phone, etc., and in most... -
Page 8: Battery And Battery Eliminator Installation
LCD goes blank at the open battery compartment. end of the countdown, the unit will not turn off. Instead, it will stay energized and the display will return to the previous screen. LECTROSONICS, INC. -
Page 9: Standby Mode
The screen displays rf OFF to remind the user that decimal numbering the unit is not transmitting. system is unique to Frequency displayed as Lectrosonics where two two-digit hexadecimal While the unit is in the standby mode, access the set- alphanumeric characters number... -
Page 10: 5-Pin Input Jack Wiring
TA5F to your particular micro- phone. A length of .065 OD clear tubing is included if insulating the resistor leads or shield wire is necessary. (Remove rubber strain relief from con- nector backshell by pulling it out of the backshell.) LECTROSONICS, INC. -
Page 11: Microphone Cable Termination For Non-Lectrosonics Microphones
VHF transmitters with 5-pin jacks require a different termination. Lectrosonics lavaliere microphones are terminated for compatibility with VHF and UHF transmitters, which is different than what is shown here. Rio Rancho, NM... -
Page 12: Microphone Rf Bypassing
Capacitors are available from Lectrosonics. Please specify the part number for the desired lead style. Leaded capacitors: P/N 15117 Leadless capacitors: P/N SCC330P All Lectrosonics lavaliere mics are already bypassed and do not need any additional capacitors installed for proper operation. LECTROSONICS, INC. -
Page 13: Wiring Hookups For Different Sources
Sanken COS-11. Simplified wiring for microphones such as negative bias TRAM. This wiring is fully compatible with 5-pin inputs on Lectrosonics NOTE: This servo bias wiring is not compatible with earlier transmitters such as the LM and UM Series. This is the wiring versions of Lectrosonics transmitters. -
Page 14: Optional Rm/E Remote Control
A single AA Lithium battery will operate the RM/E for up to several years. Unscrew the knurled knob for access to the battery compartment. LECTROSONICS, INC. -
Page 15: Operating Notes
Super-Minature Belt Pack Transmitters Operating Notes • The sensitivity to the remote control varies with the transmitter’s audio level setting and the microphone used, but it is always possible to make it work with a sufficiently loud remote signal at close range. -
Page 16: Troubleshooting
4) Receiver/Transmitter Compatibility Mode mismatched. EXCESSIVE FEEDBACK 1) Transmitter gain (audio level) too high. Check gain adjustment and/or reduce receiver output level. 2) Talent standing too close to speaker system. 3) Mic is too far from user’s mouth. LECTROSONICS, INC. -
Page 17: Rm Troubleshooting
Super-Minature Belt Pack Transmitters SYMPTOM POSSIBLE CAUSE HISS AND NOISE -- AUDIBLE DROPOUTS 1) Transmitter gain (audio level) far too low. 2) Receiver antenna missing or obstructed. 3) Transmitter antenna broken or missing. 4) Operating range too great. 5) Signal interference. Turn off transmitter. If receiver’s signal strength indicator does not drop to nearly zero, this indicates an interfering signal may be the problem. -
Page 18: Straight Whip Antennas
SMB/EO1 Series Straight Whip Antennas The Lectrosonics AMMKIT provides the parts to make The frequency range and/or block is marked on the an antenna with a standard SMA connector for any of outside of the transmitter housing. the available frequency blocks. Cut the whip accord-... -
Page 19: Included Accessories
Super-Minature Belt Pack Transmitters Included Accessories SMB: SMBCUPSL Spring-loaded Leather pouch with 35923 Thermal insulating pad machined aluminum clip integrated belt clip for SMB Place thermal insulation pad on back of unit, as pictured. SMDB: SMDBCSL PSMD Leather pouch with Spring-loaded 35924 Themal insulating pad... -
Page 20: Adjusting Audio Level (Gain)
5) If the unit was set up in Standby Mode, it will be necessary to turn the transmitter off, then power it up again in normal operation so the RF output will be on. Then the other components in the sound or recording system can be adjusted. LECTROSONICS, INC. -
Page 21: Specifications And Features
Super-Minature Belt Pack Transmitters Specifications and Features Operating frequencies: Low frequency roll-off: Adjustable from 35 to 150 Hz. Block 470 470.100 - 495.600 Block 27 691.200 - 716.700 Block 19 486.400 - 511.900 Block 28 716.800 - 742.300 Block 20 512.000 - 537.500 Block 29 742.400 - 767.900... -
Page 23: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a modest flat rate plus parts and shipping. -
Page 24: Limited One Year Warranty
This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
