• Shared: There are an unlimited
number of shared keys avail-
able. Once generated by the
DCHT and transferred to an
encryption capable receiver,
the encryption key is available
to be shared (synced) by the
receiver with other encryption
capable transmitters/receivers
via the IR port.
• Standard: Standard Keys are
unique to the DCHT. The trans-
mitter generates the Standard
Key. The DCHT is the sole
source of the Standard Key,
and because of this, the DCHT
may not receive (get) any
Standard Keys.
• Volatile: This one-time only key
is the highest level of encryp-
tion security. The Volatile Key
exists only as long as the pow-
er in both the DCHT Transmit-
ter and an encryption capable
receiver remains on during a
single session. If the receiver
is powered off, but the DCHT
has remained turned on, the
Volatile Key must be sent to
the receiver again. If the power
is turned off on the DCHT, the
entire session concludes and
a new Volatile Key must be
generated by the transmitter
and sent to the receiver via the
IR port.
MakeKey
When the transmitter key type is set
to Volatile, Standard or Shared, use
this menu item to create a key that
can be synced with an encryption
capable receiver.
WipeKey
This menu item is only available if
there is a Key Type currently on the
DCHT that can be deleted. Select
Yes to wipe the current key and en-
able the DCHT to create a new key.
www.lectrosonics.com
SendKey
This menu item is only avail-
able if Key Type is set to Volatile,
Standard or Shared, and a new
key has been created. Press
Menu/Sel to sync the Encryp-
tion key to another transmitter or
receiver via the IR port.
Key...
MakeKey
WipeKey
SendKey

Setup Menu

Selecting Programmable
Switch Functions
The programmable switch on the
top panel can be configured using
the menu to provide several func-
tions:
• (none) - disables the switch
Mute - mutes the audio when
•
switched on; LCD will blink
a message and -10 LED will
glow solid red
Power - turns the power on and
•
off
• TalkBk - redirects the audio to
a different output channel on
the receiver (only available in
DCH(X) compatibility mode)
Setup...
ProgSw
AutoOn?
ProgSw
Remote
NOTE: The programmable
switch will continue to
operate whether or not
keypad changes are locked.
SendKey
Send
Press the
and
arrow buttons
to select
Mute
the desired
function or
disable the
switch
