Lectrosonics LMb/E01 Quick Start Manual

Digital hybrid wireless uhf belt pack transmitter
Hide thumbs Also See for LMb/E01:
Table of Contents

Advertisement

Quick Links

Download this manual
Q
uick
S
tart
G
uide
LMb
Digital Hybrid Wireless
UHF Belt Pack Transmitter
LMb, LMb/E01, LMb/E06, LMb/X
Fill in for your records:
Serial Number:
Purchase Date:
®
This guide is intended to assist with
initial setup and operation of your
Lectrosonics product.
For a detailed user manual, down-
load the most current
version at:
www.lectrosonics.com/manuals
U.S. Patent 7,225,135
15 July 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LMb/E01 and is the answer not in the manual?

Questions and answers

Related Manuals for Lectrosonics LMb/E01

Summary of Contents for Lectrosonics LMb/E01

  • Page 1 Digital Hybrid Wireless ® UHF Belt Pack Transmitter LMb, LMb/E01, LMb/E06, LMb/X U.S. Patent 7,225,135 This guide is intended to assist with initial setup and operation of your Fill in for your records: Lectrosonics product. Serial Number:...

  • Page 2: Controls And Features

    Switch dot to turn it on Input Jack Power/Function Modulation LEDs 470.100 - 537.575 MHz S/N XXXXX Lectrosonics, Inc. Model: LMBC1 Made in U.S.A. IR Sync IC: 8024A-LMBC1 Port Battery icon RF Indicator Battery Status LED Reserved for Future Use...

  • Page 3: Keypad And Lcd Interface

    When the frequency step size is set to 25 kHz, the hex number is smaller and may include a fraction. Fraction b 19 Note that the 1/4 = .025 MHz frequency has MUTE 1/2 = .050 MHz increased by 25 494.525 kHz from the upper 3/4 = .075 MHz example. www.lectrosonics.com...

  • Page 4: System Setup Procedures

    Because rechargeable batteries run down quite abruptly, using the Power LED to verify battery status will not be reliable. However, it is possible to track battery status using the Battery Timer function available in Lectrosonics Digi- tal Hybrid Wireless receivers.

  • Page 5: Navigating Menus

    Rf On? Use arrow keys to turn Rf On? Rf signal on/off BACK BatType Use arrow keys to select Alk. BatType Lith. battery type BACK Default Use arrow keys to return Default settings transmitter to default BACK factory settings www.lectrosonics.com...

  • Page 6: Powering On In Operating Mode

    NOTE: If the programmable switch is in the OFF position, power can still be turned on with the power button. If the programmable switch is then turned on, a brief message will appear on the LCD. LECTROSONICS, INC.

  • Page 7: Power Menu

    Compatibility modes are as follows: • Mode 3* works with certain non-Lectrosonics models. • Nu Hybrid works with all Lectrosonics Digital Hybrid receivers. The receiver must also be set to Hybrid compatibility mode. • IFB Series works with Lectrosonics IFB R1/R1a analog receivers.

  • Page 8: Selecting Step Size

    RF interference. In other cases, a frequency may be specified by officials at a large event such as the Olympics or a major league ball game. Once the frequency is determined, set the transmitter to match the associated receiver. LECTROSONICS, INC.

  • Page 9: Adjusting The Input Gain

    6) If the audio output level of the receiver is too high or low, use only the controls on the receiver to make adjustments. Always leave the trans- mitter gain adjustment set according to these instructions, and do not change it to adjust the audio output level of the receiver. www.lectrosonics.com...

  • Page 10: Selecting Frequency

    A fraction will appear next to the hex code in the setup screen and in the main window when the frequency ends in .025, .050 or .075 MHz. b 19 Freq. b 19 Fraction appears MUTE next to hex code 494.525 in 25 kHz mode 494.525 LECTROSONICS, INC.

  • Page 11: Selecting Programmable Switch Functions

    The transfer is initiated with a switch on the receiver. IR Port 614.4 - 691.1 MHz FCCID:DBZLMBC1 S/N XXXXX Lectrosonics, Inc. Model: LMBC1 Made in U.S.A. IC: 8024A-LMBC1 The receiver can transfer the settings for Frequency, Step Size and Compat- ibility mode to the transmitter via the IR ports.

  • Page 12: Limited One-Year Warranty

    This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
