Multicell Components - SpectraLink IP-DECT Server 400 Installation And Configuration Manual

Spectralink IP-DECT Server 400 Installation and Configuration Guide
Figure 15 Base Station Configuration
Figure 16 Base Station Overview
In the example above, there are two bases in the Spectralink IP-DECT Server 400 solution. Base
station 1 is Synchronization on base 0 (Zero). Repeaters are not visible in the server, and are
add-ons to the system and are not manageable by the system. A repeater is managed directly on
the repeater itself using a PC and a repeater programming kit.

Multicell Components

The following components are available in a Spectralink IP-DECT Server 400 multicell setup. All
components are optional. A multicell license is required.
Table 2 Multicell components
Component
Spectralink IP-DECT Server
400
IP Bases
Repeaters
Multicell license
14219101 Version 3.0
August, 2013
Amount
1
3
12
1
34
