Locking or Unlocking the Control Panel

The Lock mode protects the transmitter from
accidental changes to its settings.
1)
Ensure the transmitter setup is complete.
2) Simultaneously press both the Up and Down
arrow buttons to start the Lock timer. When
the timer reaches zero, "Loc" is displayed and
the controls are locked.
Important: The only ways to unlock a locked transmitter are to
remove the battery or unlock it via remote. It cannot be unlocked or
powered off using the buttons. The remote function will work only if
the transmitter was previously configured to respond to remote. The
unit will always power up in "unlocked" mode.

Battery Installation

We recommend using lithium or high-capacity rechargeable batteries for
longest life.
Note: Standard zinc-carbon batteries marked "heavy-duty" or "long-
lasting" are not adequate.
The battery status circuitry is designed for the voltage drop over the life of
lithium batteries.
To install new batteries:
1)
Turn the Battery Cover Plate Opener counterclockwise, open the battery
compartment and remove any old
batteries.
2) Insert the new battery (or batteries) into the housing, positive (+)
terminal first.
Important: On dual-battery transmitters, BOTH
batteries go positive (+) terminal first.
3)
Replace the Battery Cover
Plate and tighten the
Opener.
www.lectrosonics.com
Do Not
Cover
Gore-
Tex® Vent
7
