Instruction Manual
Q
uick
S
tart
G
uide
SM Series Transmitters
SMa
SMv
SMQv
rM
Fill in for your records:
Serial Number:
Purchase Date:
This guide is intended to assist with
initial setup and operation of your
Lectrosonics product.
For a detailed user manual, down-
load the most current
version at:
www.lectrosonics.com/manuals
U.S. Patent 7,225,135
06 jun10
Advertisement
Table of Contents
Related Manuals for Lectrosonics sma
Summary of Contents for Lectrosonics sma
- Page 1 U.S. Patent 7,225,135 Fill in for your records: This guide is intended to assist with initial setup and operation of your Serial Number: Lectrosonics product. For a detailed user manual, down- load the most current version at: Purchase Date: www.lectrosonics.com/manuals...
-
Page 2: Controls And Functions
Used to set the operating frequency and toggle the LCD between the operating frequency in MHz and a two-digit hexadecimal frequency code. Up/Down arrows Used to adjust the selected function or parameter. Battery Compartment, Cover Plate and Opener Used to install or remove battery/batteries. LECTROSONICS, INC. -
Page 3: Standby Mode
3) From a power off condition, press and hold the Up arrow, then press the AUDIO and FREQ buttons simultaneously. 4) The LCD will display the current Compatibility Mode. Use the Up or Down arrow buttons to set the Compatibility Mode to match the corre- sponding receiver. www.lectrosonics.com... -
Page 4: Setting Transmitter Operating Frequency
Then press and hold the AUDIO button while selecting the desired roll-off frequency with the UP and DOWN arrows. The roll-off frequency can be set to 35, 50, 70, 100, 120 and 150 Hz. LECTROSONICS, INC. -
Page 5: Attaching A Microphone And Adjusting Gain
It cannot be unlocked or powered off using the buttons. The remote control will work only if the transmitter was previously configured to respond to the remote control. The unit will always power up in “unlocked” mode. www.lectrosonics.com... -
Page 6: Battery Installation
3) Replace the Battery Cover Plate and tighten the Opener. Configuring for remote Control Use Some transmitter settings can be changed with the Lectrosonics RM Remote Control. However, you must first configure the SM Series transmitter to accept commands from the RM:... -
Page 7: Powering The Rm On And Off
The FrEQ button cycles through 3 pages: 1) CH - set transmitter’s channel (using block-independent hex code) 2) b - select a block number (optional — uncovers page 3) 3) 000.000 - set transmitter’s frequency in MHz (avail. if a block is selected) www.lectrosonics.com...
