SMB Series Transmitters
SMB Series transmitters are ideal
for motion picture and television
production, live theater and other
productions where costuming is
prevalent and the wireless must be
concealed. Despite their tiny size,
the transmitters are feature rich and
well suited to demanding production
environments where outstanding
audio quality and RF performance
are mandatory in the midst of tem-
perature and moisture extremes.
Both models are compatible with
the LectroRM app from New Endian
LLC for hands free setup and ad-
justment. The transmitter can be put
to sleep to conserve battery power
during setup while the transmitter
is buried deep inside costuming,
then awakened for normal operation
when the production begins. Other
features include frequency and
audio level adjustment and control
lockout.
Operating frequencies:
Block 470 470.100 - 495.600 MHz
Block 19 486.400 - 511.900 MHz
Block 20 512.000 - 537.500 MHz
Block 21 537.600 - 563.100 MHz
Block 22 563.200 - 588.700 MHz
Block 23 588.800 - 614.300 MHz
Block 606 606.000 - 631.500 MHz
Block 24 614.400 - 639.900 MHz
Block 25 640.000 - 665.500 MHz
Block 26 665.600 - 691.100 MHz
2
E02 Additional Frequencies:
Block 27 691.200 - 716.700
Block 28 716.800 - 742.300
Block 29 742.400 - 767.900
Block 30 768.000 - 793.500
Block 31 793.600 - 819.100
Block 32 819.200 - 844.700
Block 33 844.800 - 861.900
(100 kHz Steps)
NOTE: It's the user's responsibility to select
the approved frequencies for the region
where the transmitter
is operating.
RF Power output: 50 mW
