Quantum ATL StackLink Installation Instructions Manual page 9

Installing the Bottom Mounting Tray Assembly
Figure 5 Adjusting the
Depth of the Bottom
Mounting Tray Assembly
Secure the top mounting tray assembly to the rack, using eight
5
screws (YS41803) and washers (YS40404) provided in the
StackLink kit (see
If the rack has widely spaced mounting holes, it may not
Note:
be possible to use all four screws to secure the rear
flanges. If this is the case, one screw per side at the rear is
acceptable.
Fully tighten the six screws and washers securing the rear support
6
arms to the sides of the top mounting tray.
To install the bottom mounting tray assembly in the rack:
Remove the six screws and washers securing the rear support arms
1
to the sides of the bottom mounting tray (see
Adjust the position of the rear support arms on the bottom
2
mounting tray until the distance between the front and rear flanges
is approximately the same as the distance between the front and
rear mounting strips in the rack.
Installing the Bottom Mounting Tray Assembly
Quantum|ATL StackLink™ Installation Instructions
Document 6421009-03, Ver. 3, Rel. 0
figure 4).
November 2001
0
figure 5).
