Installing the Safety Blanking Panels

Cabling the Library

18
To avoid personal injury or damage to the StackLink mechanism,
install safety blanking panels over all empty locations in the M1500
stack.
If the holes in the rack rails are square (untapped), insert caged
1
nuts into the holes where the front safety blanking panels will be
installed.
Install front safety blanking panels (212579) at the front of the rack,
2
securing each panel with two screws (YS41803) and washers
(YS40404).
Install rear safety blanking panels (212502) at the rear of the rack,
3
securing each panel with two screws (YS40095).
The library cabling procedure consists of the following steps:

• Interlibrary (control bus) cabling

• StackLink motor connection

• SCSI bus cabling

• Power cabling
