Figure 14 Securing the
Library to the Rack
Press the white button next to the left magazine access door
d
and open the door.
Notice the hole behind the magazine access door, at the lower
e
edge of the library (see
This hole provides access to the rack mount clamp screw.
Access hole
for rack mount
clamp screw
Insert a no. 2 Pozi-Driv screwdriver into the hole and turn the
f
rack mount clamp screw clockwise to tighten it fully.
As you tighten this screw, a lever protrudes from the side of the
library and presses against the rear side of the rack rail.
Repeat steps 2d
g
to the rack.
Close the magazine access doors.
h
Repeat steps 2a through
3
modules below the first one.
Install the libraries from the top of the StackLink
Note:
downward, leaving no space between the libraries. The
cable lengths are designed for libraries installed
immediately adjacent to one another.
Once all the libraries are installed, fully tighten the StackLink
4
vertical shuttle assembly (see
Installing the Libraries
Quantum|ATL StackLink™ Installation Instructions
Document 6421009-03, Ver. 3, Rel. 0
figure 14).
through 2f to secure the right side of the library
2h to install additional M1500 library
figure 13 on page 15).
