Quantum|ATL StackLink™ Installation Instructions
Document 6421009-03, Ver. 3, Rel. 0
November 2001
Installing the Libraries
16
Now that the StackLink is installed in the rack, install the libraries as
follows:
If you have not done so already:
1
Unpack and install the rack mount shelves on which the M1500
a
libraries will be placed, referring to the Quantum|ATL M1500
Universal Rack Mount Kit Installation Instructions (PN 6421004).
The libraries will be installed from the top of the rack
Note:
downward; position the rack mount shelves accordingly.
For example, if you were installing two libraries in a
5-high StackLink, you would install two sets of rack
mount shelves: one set 4U below the StackLink top
mounting tray assembly, and another set 8U below the
StackLink top mounting tray assembly.
Unpack the M1500 libraries, referring to the Quantum|ATL
b
M1500 Library Unpacking Instructions (PN 6421002).
Make sure to remove the StackLink cover plate from
Caution:
the rear of the libraries.
Install an M1500 library in the top StackLink position.
2
Verify that the rack mount shelves are level and securely
a
fastened to the rack.
With the help of another person, lift the library onto the rack
b
mount shelves.
When sliding the library into the rack, be very careful
Caution:
not to abrade or disconnect the ribbon cable that
connects the vertical shuttle assembly to the control
board on the motor assembly. See
page 14 for the location of this cable.
Slide the library all the way into the rack.
c
Installing the Libraries
0
figure 12 on
