Figure 8 Connecting the
Umbilical Cable to the
Bottom of the Carriage
Installing the Motor Assembly
12
Slide the carriage onto the top of the vertical shuttle assembly,
3
engaging the guide wheels of the carriage with the vertical rails.
Secure the umbilical chain to the bottom of the carriage, using the
4
two small countersink screws (YS41830) provided in the StackLink
kit (see figure 8).
Connect the end of the umbilical cable to the socket on the carriage
5
connection board (see
To secure the motor assembly to the vertical shuttle assembly:
Insert the bottom of the motor assembly into the top of the vertical
1
shuttle assembly, aligning the three holes in the vertical shuttle
assembly with those on the motor assembly (see
Installing the Motor Assembly
figure 8).
Umbilical
cable
Carriage
Umbilical
chain
0
figure 9).
