Figure 20 Welcome
Screen
Figure 21 Sample Main
Screen
When the POST is complete, the GUI displays the main screen (see
figure 21), where
1500 - x0 Ready
of the library, such as
If any of the library module main screens indicates
Note:
, then that particular library module has not been
1500 Ready
recognized as part of the M1500 stack. Check the interlibrary
and StackLink motor cabling.
Completing the Installation
Quantum|ATL StackLink™ Installation Instructions
Document 6421009-03, Ver. 3, Rel. 0
should indicate the maximum size
or
1500 - 40 1500 - 100
