Base Address
200 – 207
208 – 20F
.
.
2E8 – 2EF
2F0 – 2F7
2F8 – 2FF
.
.
3E8 – 3EF
3F0 – 3F7
3F8 – 3FF
NOTE:
1 . factory setting for channel 1
2 . factory setting for channel 2

2.3 Jumper Settings

Simply lift off the jumper's cap and place it on the
appropriate pair of pins (to activate/enable) or put it over the
pin (to deactivate/disable). The location diagram in Appendix
A and Appendix B will assist you in locating these jumpers.

2.3.1 JP9 (IRQ Level Selection)

JP9 selects the IRQ level (Interrupt Request), numbered from
3 through 12. The CH#1 IRQ select is located on the upper
pin row, whereas CH#2 is located at the lower pin row
position. For instance, if the I/O port of Channel #1 is set to
Hex 3F8 (COM1) and Channel #2 to Hex 2F8 (COM2) then the
jumper JP9 must be selected respectively. See the setting of
JP9 on Figure 1.
WARNING:
Setting up the AX10445
A8 A7
ON ON
ON ON
ON OFF OFF
ON OFF OFF
ON OFF OFF
OFF OFF OFF
OFF OFF OFF
OFF OFF OFF
The IRQ number for each channel must not
b e t h e s a m e .
AX10445 Module Series User's Manual
A6 A5 A4
ON ON ON
ON ON ON
OFF ON
OFF OFF
OFF OFF
OFF ON
OFF OFF
OFF OFF
A3 Connect
ON
OFF
OFF C O M 4
ON
OFF
C O M 2 * 2
OFF C O M 3
ON
OFF C O M 1 * 1
