- Page 1 AX92324 2-Port 10GbE PoE PCI Express Card User’s Manual...
- Page 2 Disclaimers This manual has been carefully checked and believed to contain accurate information. Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or rights of any third party, or any liability arising from such use. Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy, completeness or usefulness of any information in this document.
-
Page 3: Esd Precautions
When handling boards and components, wear a grounding wrist strap available from most electronic component stores. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. ® Windows is a trademark of Microsoft Corporation. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation. -
Page 4: Table Of Contents
Table of Contents Disclaimers ..................... ii ESD Precautions ................... iii Section 1 Introduction ..........1 General Description ................1 Features ....................1 Specifications ..................2 Dimensions ..................3 Section 2 Connectors ..........5 Connectors ..................5 2.1.1 12/24V Power Input (ATX1) ................ 5 2.1.2 4-pin Molex Male connector (ATX2) ............ -
Page 5: Introduction
Dimensions General Description The AX92324 is a dual-port 10GbE PCI Express LAN card based on the Intel® Ethernet Controller X550-AT2. To meet the demands of the next-generation 10GbE cameras with high resolution and high-speed transmission over one single Ethernet cable, the AX92324 features the combination of 10GbE and IEEE802.3at compliant PoE capabilities. -
Page 6: Specifications
2.1A @ +12V 1.2A @ +3.3V Power from the ATX power connector: (Max. 60W POE power output) 6A @ +12V or 3A @ +24V* (*24V power is for Axiomtek’s products) 1.2A @ +3.3V (from PCIe slot) 30W@54VDC power output (per port) Environmental Operating temperature: 0°C ~ 550°... -
Page 7: Dimensions
AX92324 2-port 10GbE PoE PCI Express Card Dimensions Component Side Solder Side Introduction... - Page 8 AX92324 2-port 10GbE PoE PCI Express Card This page is intentionally left blank. Introduction...
-
Page 9: Connectors
RJ-45 Connector (LAN1 & 2) 2.1.3 Jumper (JP1) 2.1.4 Note: ATX1, ATX2 and JP1 are available in the PoE version of AX92324 only. 2.1.1 12/24V Power Input (ATX1) The power connector is used for PoE function when total power of powered device is over 20 watts. -
Page 10: 4-Pin Molex Male Connector (Atx2)
AX92324 2-port 10GbE PoE PCI Express Card 2.1.2 4-pin Molex Male connector (ATX2) The power connector is used for PoE function when total power of powered device is over 20 watts. Signal +12V 2.1.3 RJ-45 Connector (LAN1 & 2) Description... -
Page 11: Jumper1 (Jp1)
15-16 close Note: If using only one piece of AX92324 on your system, you can ignore this setting. When using two or more pieces of AX92324 on your system, you must set a different board ID for each piece. Connectors... - Page 12 AX92324 2-port 10GbE PoE PCI Express Card This page is intentionally left blank. Connectors...
-
Page 13: Poe Manager Software
AX92324 2-port 10GbE PoE PCI Express Card Chapter 3 PoE Manager Software Management software AMSIO PoE Manager is a highly integrated software management system that provides an easy-to-use application programming interface. Software Structure AMSIO PoE Manager is an intelligent software tool for managing PoE (Power over Ethernet) devices, ranging from physical layer connectivity and communication layer protocols to middleware API and high level software for management. -
Page 14: Amsio Poe Manager
AX92324 2-port 10GbE PoE PCI Express Card AMSIO PoE Manager AMSIO PoE Manager is a software program that helps to monitor and manage PoE (Power over Ethernet) operations. The major task of PoE manager is to routinely monitor each PoE port’s power consumption and status. If any problem happens to a port, it will display info imagery for the user. -
Page 15: Menu Bar
AX92324 2-port 10GbE PoE PCI Express Card Menu Bar On the top of the main screen is the menu bar. Select the tab in this bar to go to the submenus. 3.3.1 File Polling rate Set the polling rate to monitor PoE power consumption and port status. Polling rates... -
Page 16: Menu List
AX92324 2-port 10GbE PoE PCI Express Card Menu List The menu list is located on the left frame of the screen and contains all monitoring and control functions. It has two submenus: “Information” and “Control”. PoE Manager menu list Information The information menu includes the "General"... -
Page 17: Features
AX92324 2-port 10GbE PoE PCI Express Card Features 3.5.1 Information General General page Board ID: The board ID displays the board number and the module’s name. The user can click the drop-down list to display other module information. Port1-2: The tab sort shows all available device ports. - Page 18 AX92324 2-port 10GbE PoE PCI Express Card Power Chart PowerChart page Chart: The chart describes power consumption by each port and total amount of unused power. It uses percentage to represent ratio of each port. User Defined Power Budget: The power budget shows the upper limit of power consumption defined by the user.
-
Page 19: Control
AX92324 2-port 10GbE PoE PCI Express Card 3.5.2 Control Chip Chip page Max Power Budget: This function shows the module’s max power value. The user cannot set power budget higher than max power budget. User Defined Power Budget: The user can define any power budget value, which cannot exceed max power budget.
