Technical Data; Interface Assignment; Fig. 12-4: Pin Assignment Of Rs 232C X35, X36; Fig. 12-5: Pin Assignment Of Rs422/485 X40, X41 - Rexroth Indramat SYSTEM200 Project Planning Manual

RECO PLC ISP200-R/G2

12.4 Technical Data

12.5 Interface Assignment

DOK-CONTRL-MTS-R0*.2G2-PR01-EN-P
Supply
Supply voltage:
Power consumption:
Interface data
Input capacity:
Input leakage current:
Output capacity:
Output current (switching actively 0):
The assignments of the serial interfaces are as follows:
PIN Signal name
1 DCD / Data Carrier Detect
3 TxD / Transmit Data
5 SGND / Ground
7 RTS / Ready To Send
9 RI / Ring Indicator

Fig. 12-4: Pin assignment of RS 232C X35, X36

PIN Signal name
1 GND / Frame Ground
3
TxD A (-) / Transmit Data
5 SGND / Signal Gound
7 RTS / Ready To Send
9
TxD B (+) / Transmit Data

Fig. 12-5: Pin assignment of RS422/485 X40, X41

Serial Interfaces
4.5 to 5.5 VDC
Max. 250 mA
Max. 15 pF
Max. 5 µA
Min. 150 pF
Min. 12 mA
PIN Signal name
2 RxD / Receive Data
4 DTR / Data Terminal Ready
6 DSR / Data Set Ready
8 CTS / Clear To Send
PIN Signal name
2 NC
4
RxD A (-) / Receive Data
6
RxD B (+) / Receive Data
8 CTS / Clear To Send
12-3
