11.3 Status and Diagnostic Displays

11.4 Technical Data

DOK-CONTRL-MTS-R0*.2G2-PR01-EN-P
With the start of the DNM03 a self-test is started, whereby the yellow RDY
LED lights up after the initialization time (2-3 seconds) after an error-free
test cycle. Otherwise, the RDY LED starts to flash and the program
execution is interrupted. The further meanings of the indicators during the
initialization phase are listed below.
RDY LED yellow:
ON:
Flashes cyclically:
Flashes irregularly:
OFF:
RUN LED green:
ON:
Flashes cyclically:
Flashes irregularly:
OFF:
NET ON green:
Flashes green:
ON red:
Flashes red:
OFF:
MOD ON green:
Flashes green:
ON red:
Flashes red:
OFF:
Supply
Operating voltage:
Op. voltage DeviceNet interface:
Interface data
Communication interface:
Diagnostic interfaces:
Operating conditions
Operating temperature:
Storage temperature:
Relative humidity:
DeviceNet Master Connection
Ready
DPM01 or DPS01 ready for operation
Bootstrap loader active
Hardware or system error
Hardware defective
RUN (communication)
Communication runs
Communication stopped
Missing or wrong configuration
No communication
Communication at the bus established
No communication at the bus
Critical connection error
Time monitoring error
No operating voltage, not at the bus
Device works
Ready for operation
Non-correctable error
Subordinated error
No operating voltage
+5 V ±5 % / 650 mA
+11 V – +25 V / 55 mA
ISO 11898, max. 500 kbaud, isolated
RS232C, 9600 baud, non-isolated
0 °C - +55 °C
-25 °C - +70 °C
Max. 75%, condensation to be avoided
