15-4
Accessories

15.2 Labeling of I/O Modules

Description
Carrier foil
Labeling foil
Labeling package
A labeling package (SUP-M03-RECO) is available for additionally labeling
the RECO02 I/O modules. This package consists of 16 carrier foils, 10
labeling foils with 6 adhesive strips each, and the labeling software. The
carrier foil can be glued on the left or right of the module housings. It is
intended to take up the prepunched adhesive strips, six of which are
provided on each labeling foil in A4 size.
The moisture-resistant labeling foils (SUP-M02-RECO) are suitable for
labeling with a commercially available laser printer. The adhesive foils are
labeled by means of the enclosed labeling program, which is designed on
Word basis and permits labeling of 1 to 6 modules per labeling foil. When
doing this, the user can select whether the module concerned is a 16-bis,
a 32-bit, an input or an output module and whether the label is to be
adhered onto the left or onto the right side of the module. To ensure
correct operation of the labeling program, it must be filed in the templates
folder of Microsoft Office. The program is started by executing <File/New>
in Word.
Depending on the printer driver, the format of the template may be slightly
different. To achieve best results, we recommend to use Xerox DocuTech
135 PS2.
Type
SUP-M01-RECO
SUP-M02-RECO
SUP-M03-RECO

Fig. 15-2: Labeling accessories

RECO PLC ISP200-R/G2
Material no.
281 697
281 696
286 977
DOK-CONTRL-MTS-R0*.2G2-PR01-EN-P
