Installation Sizes Of The Rmb02.2-04 Module Carrier - Rexroth Indramat SYSTEM200 Project Planning Manual

RECO PLC ISP200-R/G2

Installation Sizes of the RMB02.2-04 Module Carrier

2
42
DOK-CONTRL-MTS-R0*.2G2-PR01-EN-P
Locking screw for
locking the chassis
on the top hat rail
182
42 121
S1
Fig. 4-4: RMB02.2-04 module carrier
182
121
S1
182
Fig. 4-5: Connection of several RMB02.2-04 module carriers
Technical Data
12
9
56
7
54.5
Top hat rail
TS 35 x 27 x15
RMB02.2-04_Maß.FH7
182
S1
RMB02.2-04+02-04_Maß.FH7
4-5
RMB02.2-04_Maß.FH7
RMB02.2-04+02-04_Maß.FH7
