RECO PLC ISP200-R/G2
4

Technical Data

4.1

General Features

Mounting in the control cabinet:
Housing dimensions (W x H x D):
Weight:
Protection category:
Permissible temperature:
Relative humidity:
Air pressure:
4.2

Supply Voltage

Nominal value:
Tolerance:
Ripple percentage:
Permissible voltage range:
Max. current consumption for 24 V
Required fuse in the supply cable:
Cable cross-section for supply voltage:
4.3

I/O Bus Supply by the Control

Module supply 24 V:
Module supply 5 V:
Total power:
4.4

Derating of the I/O Bus Supply

0 – 35 °C
35 – 45 °C
45 – 55 °C
DOK-CONTRL-MTS-R0*.2G2-PR01-EN-P
Module carrier RMB02.2 / RMB04.2
MTS-R01.2 = 41.5 x 192 x 150 mm
MTS-R02.2 = 83.7 x 192 x 150 mm
MTS-R01.2 = 1.1 kg
MTS-R02.2 = 1.3 kg
IP 20, EN 60529
Operation
Storage/temperature
Operation
Storage/temperature
Operation
Storage/temperature
24 V
-15 % / +20 % (according to EN 61131-2 1994)
5 % max.
19,2...30 V
DC
(MTS-R01): 0.5 A
(MTS-R02): 0.7 A
(supply voltage for I/O bus is up to max. 2.3 A)
Max. 4 A time-lag for 24 V
0,75...1,5 mm
0...+55 °C
-25...+70 °C
10...95 %, condensation to be avoided
5...95 %, condensation to be avoided
86...106 kPa
70...106 kPa
DC
(including ripple content)
DC
2
(depending on current demand)
Max. 2.2 A
Max. 3.0 A
Max. 52 W (observe the derating)
100 % (52 W)
85 % (44 W)
75 % (39 W)
4-1
Technical Data
