6-6
Startup
6.4

RecoBus in the PLC Memory

Diagnostic double word:
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Memory assignment in the input area
Byte
0
position
Byte 0
8
H1
X60
X10
X64
U1
X16
X1
MTS-R02.2
Byte 0
Byte
0
position
Memory assignment in the output area
As the I/Os in the PLC memory are gapless imaged some principles have
to be considered while programming the inputs and outputs. The PLC
always requires 4 bytes in the input area for the diagnostic double word.
The diagnostic double word permits an exact diagnosis of the connected
modules (see 6.5 RecoBus Diagnosis). Thus, the first input module is
imaged as of byte position 4. The output modules are imaged in the
output area of the PLC as of byte position 0. During the assembly of the
module carriers it is possible to leave gaps, so that modules can be fitted
later. For this, modifications in the PLC program in the declaration or the
I/O editor have to be made, as the additional module inserted in a gap
displaces the starting address of the following modules by the data width
of the plugged-in module.
Error Module status Slot address
1 2 3 4
Byte 1 Byte 2 Byte 3 Byte 0 Byte 1 Byte 0 Byte 1 Byte 2 Byte 3
REC
X1
X35 X40
X36 X41
X2
U2 U3
RMA02.2-16-DC024-200
Byte 1 Byte 0 Byte 1 Byte 2 Byte 3
1 2 3 4
Fig. 6-7: RecoBus I/O modules in the memory of the PLC
Error No.
5 6 7 8 9
X1 X1
X1
X2 X2
X3 X3
X2
X4 X4
RMA02.2-32-DC024-050 RME02.2-16-DC024 RME02.2-32-DC024
Byte 0 Byte 1 Byte 2 Byte 3
5 6 7 8 9
RECO PLC ISP200-R/G2
10 11 ...... 31
X1
X2
X3
X4
RMA02.2-32-DC024-050
10 11 31
......
IO-Belegung RECO_3.FH7
DOK-CONTRL-MTS-R0*.2G2-PR01-EN-P
