HDMI KVM EXTENDER OVER NETWORK CABLE
q: Abnormal color display or flashing after all the devices are well
connected?
a: 1) Pls press reset button of HDMI extender.
2) Make sure the network cable is made according to the standard
EIA-568B.
q: U SB does not work?
a: Re-install the driving software, check and make sure the USB
cables are connected well, then reset Transmitter and Receiver.

sPEcIFIcaTIoN

HDMI version
HDcP version
Video bandwidth
HDMI resolution
supported
audio support
HDMI connector
LaN connection
working temperature
Relative humidity
Power supply
Power consumption
Product dimension
weight
color
Maintenance: clean only with a dry cloth. Do not use cleaning
solvents or abrasives.
warranty: no guarantee or liability can be accepted for any changes
and modifications of the product or damage caused due to incorrect
use of this product.
In compliance with EU Directive WEEE this product is marked
with this symbol. It means that used electrical and electronic
products should not be mixed with general household waste.
There is a separate collections system for these products in
compliance with WEEE directive, otherwise contaminative and
hazardous substances can pollute the environment.
With the CE sign, Techly
to the basic European standards and directives.
HDMI1.3
HDCP1.2
≤70Mbps
640*480@60Hz, 800*600@60Hz,
1024*768@60Hz, 1280*720@60Hz,
1360*768@60Hz, 1440*900@60Hz,
1400*1050@60Hz, 1680*1050@60Hz,
1920*1080@60Hz
PCM (44.1KHz, 48Khz)
Type A, 19-pin, female
RJ45
0°C ~ 50°C
10-95% (non condensing)
5V / 1A *2pcs
TX<3.5w RX<3.5w
109 x 89.5 x 26.3 mm * 2pcs
Tx:160g RX:170g
Black
ensures that the product is conformed
®
EN
