Fronius Robacta TC 2000 ext. Operating Instructions Manual page 48

3
4
48
(1)
Move the welding torch to the starting position above the cleaning aperture – approx-
imately 50 mm (1.97 in.) above the cleaning aperture and centrically with respect to
the middle of the cleaning aperture
- The cleaning process is completed and the welding torch is ready for use again
Make sure that not too much parting agent has collected at the gas nozzle (no forma-
tion of drops). If this is the case:
- reduce the injection time, or
- after the cleaning process, blow out the welding torch with compressed air
through the hosepack
Move the welding torch to the injection
1
position
- See graphic
NOTE! During the injection pro-
cess, do not blow out compressed
air through the welding torch.
Inject parting agent into the welding
2
torch for approximately 0.7 seconds
